UT2F/G6-0ESYIO
MICRO DETECTORS
1
Ultrasonic sensor M30 housing with large shape transducer ф 38,8 mm, analogic 4-20 mA+ PNP NO/NC, 350-6000 mm, plug M12 with teach-in button, cULus, IO-Link
Encoders
* Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Nominal sensing distance | 6000mm | |
Thermal drift of Sr | ±5% | |
Repeat Accuracy | 0,1%valore fondoscala | |
Beam angle | 15° ± 2° | |
Resolution | 0,1%valore fondoscala | |
Sensitivity adjustment | bottone teach-in | |
Hysteresis | 1% valore fondoscala | |
thermal compensation | Sì | |
Minimum sensing distance (blind zone) | 350mm | |
Linearity error | 1% valore fondoscala |
Output type | IO-Link | |
Output Function | rampa positiva | |
Switching frequency | 1Hz | |
Response time | 1s |
Operating Voltage | 10 - 30Vdc | |
No-Load supply current | 25mA | |
Load current | 100mA | |
Leakage current | ≤ 10µA @ 30Vdc | |
Output voltage drop | 2,2V max @ IL=100mA | |
Max ripple content | 5% | |
LED indicators | Verde: Eco - Giallo: Uscita | |
Time delay before availability | ≤400ms | |
Short-circuit protection | Sì | |
Reverse Polarity Protection | Sì | |
Impulsive Overvoltage Protection | Sì |
Dimensions | ø 38,8mm / L = 99mm | |
Weight | 170g | |
Housing Material | PBT | |
Connections | M12 Plug | |
Tightening torque | 1,5Nm | |
Operating temperature | -20°C…+70°C | |
Storage temperature | -30°C…+80°C | |
Transducer Frequency | 75KHz |
Approvals | CE cULus | |
EMC compatibility | IEC 60947-5-2 | |
Shocks and vibrations | IEC EN 60947-5-2 / 7.4 | |
Degree of protection | IP67 |
Supplied Accessories | 2 x M30x1,5 dadi, 2 rosette Ø 30 |
