UT1B/GM-0ESY MICRO DETECTORS Ultrasonic sensor M30 NPN adjustable hysteresis/standard window/NO+NC. 250-3500..
UT1B/GM-0ESY
MICRO DETECTORS
Ultrasonic sensor M30 NPN adjustable hysteresis/standard window/NO+NC. 250-3500 mm conn. M12 with teach-in button, plastic, cULus
Encoders
* Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
Best sellers
▲More info
▲Technical features
Detection properties
| Nominal sensing distance | 3500mm | |
| Thermal drift of Sr | ±5% | |
| Repeat Accuracy | 0,1%valore fondoscala | |
| Beam angle | 12° ± 2° | |
| Resolution | 0,1%valore fondoscala | |
| Sensitivity adjustment | bottone teach-in | |
| Hysteresis | 1% valore fondoscala | |
| thermal compensation | Sì | |
| Minimum sensing distance (blind zone) | 250mm | |
| Linearity error | 1% valore fondoscala | |
Outputs
| Output type | analog+digitale | |
| Output Function | rampa positiva | |
| Switching frequency | 1Hz | |
| Response time | 1s | |
Electrical data
| Operating Voltage | 10 - 30Vdc | |
| No-Load supply current | 25mA | |
| Load current | 100mA | |
| Leakage current | ≤ 10µA @ 30Vdc | |
| Output voltage drop | 2,2V max @ IL=100mA | |
| Max ripple content | 5% | |
| LED indicators | Verde: Eco - Giallo: Uscita | |
| Time delay before availability | ≤400ms | |
| Short-circuit protection | Sì | |
| Reverse Polarity Protection | Sì | |
| Impulsive Overvoltage Protection | Sì | |
Mechanical data
| Dimensions | M30 x 1,5 / L = 98mm | |
| Weight | 140g | |
| Housing Material | PBT | |
| Connections | M12 Plug | |
| Tightening torque | 1,5Nm | |
| Operating temperature | -20°C…+70°C | |
| Storage temperature | -30°C…+80°C | |
| Transducer Frequency | 112KHz | |
Test/Approvals
| Approvals | CE cULus | |
| EMC compatibility | IEC 60947-5-2 | |
| Shocks and vibrations | IEC EN 60947-5-2 / 7.4 | |
| Degree of protection | IP67 | |
Accessories
| Supplied Accessories | 2 x M30x1,5 dadi, 2 rosette Ø 30 | |
Dimension (mm)
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE MICRODETECTORS EN.pdf | 4 Mbytes |
|
| Download general catalog |
|
