FBLH/X0-1E
MICRO DETECTORS
1
Photoelectric sensor Axial laser emitter 50 m Check metallic connector M12
Encoders
* Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Nominal sensing distance | 50m | |
Thermal drift of Sr | ≤10% Sr |
Function Principle | Through beam | |
Emitter/Receiver | Emitter | |
Check Input | BK/2 connected to 0Vdc swithing off the emission | |
Optic position | Axial |
Operating Voltage | 10-30Vdc | |
No-Load supply current | ≤25mA | |
Max ripple content | 10% | |
LED indicators | Green (power ON) yellow (Emiss. ON) yellow(Emiss. OFF) | |
Time delay before availability | ≤200ms | |
Reverse Polarity Protection | Polarity inversal, Inpulsive voltage | |
Emission | Red laser diode (650nm) class1 (IEC60825-1) |
Dimensions | M18 x 1 /L =80 mm | |
Weight | 70g | |
Housing Material | Nicked plated brass PA12 | |
Connections | M12 Plug | |
Active Head Material | Glass | |
Tightening torque | 25Nm | |
Operating temperature | - 15°C…+ 55° C (Without freeze) |
Approvals | CE, cULus | |
EMC compatibility | EN 60947-5-2 | |
Shocks and vibrations | Vibration IEC 60068-2-6 / Shock IEC 60068-2-27 | |
Degree of protection | IP67 |
Supplied Accessories | nuts M18 x 1 |
Title: | Size: | Type: |
---|---|---|
PDF CATALOGUE MICRODETECTORS EN.pdf | 4 Mbytes | |
Download general catalog |
