FALH/X0-0E MICRO DETECTORS Photoelectric sensor Axial laser Emitter 50 m, with check, plastic plug M12
FALH/X0-0E
MICRO DETECTORS
Photoelectric sensor Axial laser Emitter 50 m, with check, plastic plug M12
FALH/X0-0E Photoelectric sensor Axial laser Emitt. 50 m Check plast. conn. M12
Encoders
* Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
Best sellers
▲More info
▲Technical features
| Nominal sensing distance | 50m | |
| Thermal drift of Sr | ≤10% Sr | |
Application
| Function Principle | Through beam | |
| Emitter/Receiver | Emitter | |
| Check Input | BK/2 connected to 0Vdc swithing off the emission | |
| Optic position | Axial | |
Electrical data
| Operating Voltage | 10-30Vdc | |
| No-Load supply current | ≤25mA | |
| Max ripple content | 10% | |
| LED indicators | Green (power ON) yellow (Emiss. ON) yellow(Emiss. OFF) | |
| Time delay before availability | ≤200ms | |
| Reverse Polarity Protection | Polarity inversal, Inpulsive voltage | |
| Emission | Red laser diode (650nm) class1 (IEC60825-1) | |
Mechanical data
| Dimensions | M18 x 1 /L =97,6mm | |
| Weight | 30g | |
| Housing Material | PBT | |
| Connections | M12 4pin Plug | |
| Active Head Material | Glass | |
| Tightening torque | 1Nm | |
| Operating temperature | - 15°C…+ 55° C (Without freeze) | |
Test/Approvals
| Approvals | CE, cULus | |
| EMC compatibility | EN 60947-5-2 | |
| Shocks and vibrations | Vibration IEC 60068-2-6 / Shock IEC 60068-2-27 | |
| Degree of protection | IP67 | |
Accessories
| Supplied Accessories | nuts M18 x 1 | |
Electrical diagrams of the connections
Connector
Dimension (mm)
Response curves
Dimensione Spot
Disassamento Parallelo
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE MICRODETECTORS EN.pdf | 4 Mbytes |
|
| Download general catalog |
|
