RED20-110S15W MEANWELL DC-DC Converter for PCB, Input: 43-160VDC. Output: 15VDC. 20W. Railway and Industry. ..
RED20-110S15W
MEANWELL
DC-DC Converter for PCB, Input: 43-160VDC. Output: 15VDC. 20W. Railway and Industry. Regulated isolated output.
ADAPTERS > AC plug
Brand new product in its original packaging covered by the warranties and certifications provided by MEANWELL
Best sellers
▲More info
▲| Name | RED20-110S15W |
|---|---|
| Long Description | Dc/DC converter Rail is a Regulated Isolated Output. Converter for Railway applications, Industrial or Telecommunications. Input range43-160Vcc. Output voltage15vdc. Output intensity3A Power:20W. Isolation input-output 2250Vcc. Efficiency of 89%. Dimensions (Length x Width x Height):50.8 x 25.4 x 10.2 mm. Operating temperature of the box from -40ºC up to +101ºC (see the curve derived in the technical data sheet). This converter is a converter designed for railway applications, industrial or telecommunications. Is certified with the regulations for railway EN50155 and EN45545-2 in front of the fire. No minimum load requirement and consumption without expensive very low. It has a low noise and ripple, as well as a high efficiency and is protected against reverse polarity at the input. Its output is protected against short-circuits and overloads by limiting output current, this allows you to start loads with a high inrush. Adjustable output voltage, through a resistance connected across the terminals of Trim 1 and Trim 2, up to 20% less than its value. Remote on / off. 3 Years of warranty. Manufacturer: P-DUKE |
| Country of Origin | Taiwan |
| Manufacturer | P-DUKE |
| Product type | Dc/DC converters |
| Format | For Printed Circuit |
| Subformato | DIP |
| Applications | Building automation, Rail, Industrial, Instrumentation, Telecommunications |
| Series | RED20 |
| Warranty (Years) | 3,00 |
| Height (mm) | 10.2 |
| Width (mm) | 25.4 |
| Long/Background | 50.8 |
| Input range | 4:1 |
| Range DC Input | 43, 46,8, 50, 50,2, 50,4, 52, 56, 60, 62,4, 64,4, 67,2, 72, 75, 77, 88, 93,6, 100, 110, 143, 144, 150, 154, 160 |
| DC input Min | 43,00 |
| DC input Max | 160,00 |
| Input connector | Pin |
| Output voltage | 15,00 |
| Power (W) | 20,00 |
| Peak Power (W) | Twenty |
| Output connector | Pin |
| Isolation (V) | 2.250,00 |
| Approvals | CE, UL |
