MOP06-24D15WB MEANWELL DC-DC converter for PCB mount, Input: 9-36VDC. Outputs: -15 / +15VDC.Power: 6W.Isolat..
MOP06-24D15WB
MEANWELL
DC-DC converter for PCB mount, Input: 9-36VDC. Outputs: -15 / +15VDC.Power: 6W.Isolation 3000VDC. DIP special. Médico.
INVERTERS > IRC
Brand new product in its original packaging covered by the warranties and certifications provided by MEANWELL
Best sellers
▲More info
▲| Name | MOP06-24D15WB |
|---|---|
| Long Description | Dc/DC converter to the printed circuit board in format DIP, with 2 outputs andregulations medical. Plastic box, free standard. FormatDIPfor soldering on printed circuit boards. Input range9-36Vcc. Outputs: -15vdc:
+15vdc:
Power:6W. Isolation input-output 3000Vca. Efficiency typical: 88.5 per cent. Low noise and ripple 50mVp-p. Low leakage current2µA. Working temperature: from-40up+105ºC. See the curve of drift according to the temperature in the technical data sheet. Dimensions (Length x Width x Height) [mm]:31,8 x 20,3 x 10,2. 5 years of warranty. Manufacturer: P-DUKE. The converters of the series MOP06 have a wide input range 2:1 or 4:1 and an isolation between input and output of 3000Vca. Are protected against overloads and short-circuits. Have a minimum consumption without load as well as a low leakage current. CE certified and UL listed. |
| Country of Origin | Taiwan |
| Manufacturer | P-DUKE |
| Product type | Dc/DC converters |
| Format | For Printed Circuit |
| Subformato | DIP |
| Applications | Automation of Buildings, Industrial, Instrumentation, Medical, Solar, Telecommunications |
| Series | MOP06 |
| State | New |
| Warranty (Years) | 5,00 |
| Height (mm) | 10.2 |
| Width (mm) | 20.3 |
| Long/Background | 31.8 |
| Input range | 4:1 |
| Range DC Input | 9, 9,2, 9,9, 10, 10,5, 10,8, 12, 13,2, 13,5, 14, 14,4, 15, 16,2, 16,5, 16,8, 18, 19, 20,4, 21, 21,6, 22,5, 24, 25,2, 26,4, 28, 28,8, 30, 31,2, 32, 32,4, 33,6, 35, 36 |
| DC input Min | 9,00 |
| DC input Max | 36,00 |
| Input connector | Pin |
| Output 1 | -15 |
| Output 2 | +15 |
| Power (W) | 6,00 |
| Peak Power (W) | Six |
| Output connector | Pin |
| Isolation (V) | 3.000,00 |
| Approvals | CE, EN60601 3rd Edition, UL, UL60601 3rd Edition |
