CEN-75-48 MEANWELL AC-DC Single output LED driver Mix mode (CV+CC), Output 48VDC / 1.57A

LED driver.

Specially designed for powering LEDs directly in a steady stream.

Format in metal boxIP66.

Input range90-295Vca47-63Hz.

Output in constant current1570mA.Adjustable by external potentiometer (1180-1570mA).

Range of output voltage with current mode constant36 to 48vdcaccording to demand load.

Output voltage with current mode constant48vdc.Adjustable by external potentiometer (43-53Vcc).

Power:75,3 W.

Efficiency typical:91%.

Potentiometers:This model incorporates 2 external potentiometers that allows us to regulate the output voltage and the maximum output current.

Input class I with grounding.

Factor corrector, power>0.95to 230vac at full load.

Operating temperature range of caseTcfrom-30ºCup+70ºC.

Dimensions (Length x Width x Height):185 x 62,5 x 40,5 mm

3 years of warranty.

Manufacturer: MEAN WELL.

The series CEN are LED Drvers designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.

This source can operate in either Constant Current when we connect the LEDs directly to have a voltage within the Range of Output Voltage mode Constant Current and a working current equal to the output current. The output voltage and the output current can be adjusted byexternal potentiometerslocated in the housing of the source.

With metal housing, suitable for LED lighting and signalling mobile in dry environments, humid, and wet conditions. Valid for interior and exterior. This model has a noise and ripple maximum of 2.4 Vp-p, so that should not be used with controllers, just to feed directly into LEDs. Complies with the requirements of security at the global level for lighting. Test burn at 100% load. High reliability with PFC (correction Factor for Power) is active.
