DRC-60A
MEANWELL
1
Available Ship on today
AC-DC Industrial DIN rail power supply with UPS function, Output 13.8VDC / 2.8A + 13.8VDC / 1.5A, with battery charger output
SECURITY > DRC
* Brand new product in its original packaging covered by the warranties and certifications provided by MEANWELL
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Name | DRC-60A |
---|---|
Long Description | UPS input switches and output continuously. Format to install on a Din rail. Range of universal input90-264vac. 47-63Hz. Output voltagefor the loadwith power: 13,8 Vdc. Output voltage in battery mode: voltage of the battery. Output intensity2.8 To. Peak Of 4.3 A. Float voltageadjustable12-15vdc. (The setting of the float voltage also adjusts the output voltage of power supply). Intensity of load1.5 To. Power:59,3 W. Type of batteries:Gel, AGM and wet. Battery capacity:5-15Ah. Efficiency typical:86%at full load with power. Protection against deep discharge of the batteries. No cut in output in the step feed mode to battery mode. 0ms transfer time. Alarms correct power AC-OK and low-battery via relay. LED to indicate proper output DC-OK. Working temperature: from-30up+70 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift. Dimensions (Width x Height x depth) [mm]:40 x 90 x 100. 3 years of warranty. Manufacturer: MEAN WELL. The series DRC-60 are Upss with input switches and output continuously. When there is mains power the computer gives a stable output while charging the battery. In case of failure of power supply maintains the output fed from the battery. These power supplies are suitable for security applications, access control and any application that must continue to function even with a power outage. These are protected against overloads, short-circuit in the output, sobrentesión output, low battery and reverse battery polarity (by fuse). They also have alarms through relay which alert us in case of network failure or when the output voltage is lower than a certain value, indicating that the capacity of the battery is low. |
Country of Origin | China |
Stock | Yes |
Manufacturer | MEAN WELL |
Product type | UPS |
Format | Din Rail |
Subformato | Narrow |
Applications | Building automation, Industrial, Telecommunications |
Series | DRC-60 |
Warranty (Years) | 3,00 |
Height (mm) | 90.00 |
Width (mm) | 40.00 |
Long/Background | 100.00 |
Type of Entry CA | Single-phase |
Input connector | Screw-Type |
Output 1 | +12 |
Power (W) | 59,30 |
Peak Power (W) | 59.3 |
Battery type | Lead, AGM, Wet |
Oh | 7, 8, 9, 10, 12, 15, 20, 24, 25, 26 |
Charge stages | Two |
Output connector | Screw-Type |
Alarms | Low battery, Input OK |
Isolation (V) | 3.000,00 |
Approvals | CE, UL |
