PLM-12E-500
MEANWELL
1
Available Ship on today
AC-DC Single output LED driver Constant Current (CC), Input 110-295VAC, Output 0.5A / 15-24VDC, Class II, push terminal block connectors
LED DRIVERS > PLM
* Brand new product in its original packaging covered by the warranties and certifications provided by MEANWELL
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Name | PLM-12E-500 |
---|---|
Long Description | LED driver. Specially designed for powering LEDs directly in a steady stream. Format in plastic boxIP30. Range of rntrada180-295Vca47-63Hz Output in constant current500mA. Range of output voltage with current mode constant15 to 24vdcaccording to demand load. Power:12W. Efficiency typical:83%. Input class II without grounding. Factor corrector, power>0.95to 230vac at full load. Consumption without load<0.5 W. Operating temperature range of caseTcfrom-30ºCup+50ºC. Dimensions (Length x Width x Height):145 x 38 x 22mm. 2 years of warranty. Manufacturer: MEAN WELL. The series PLM-E are LED drivers designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream. This source works on a Constant Current when we connect the LEDs directly to have a voltage within the Range of Output Voltage mode Constant Current and a working current equal to the output current. With plastic case, the series PLM-E has a small and compact size. Connection is by screw and protection, anti-pull, without the need of put terminals to make the connections. With ventilation for free circulation of air. With active PFC and high reliability at low cost. Indicated for interior applications, lighting, office, LED lighting and signalling mobile (roads, screens). Complies with all regulations of lighting. |
Country of Origin | China |
Manufacturer | MEAN WELL |
Product type | LED Driver |
Format | Box |
Subformato | IP30 |
Applications | Lighting |
Series | PLM-12E |
State | Recommended Model |
Warranty (Years) | 2,00 |
Height (mm) | 22.00 |
Width (mm) | 38.00 |
Long/Background | 145.00 |
Type of Entry CA | Single-phase |
AC input Min | 180,00 |
AC input Max | 295,00 |
Input frequency | 50 Hz, 60 Hz |
Input connector | Screw-Type |
Intensity of Minimum Output (mA) | 500,00 |
Intensity of Output Maximum (mA) | 500,00 |
Output current mA | Five hundred |
Power (W) | 12,00 |
Peak Power (W) | Twelve |
Output connector | Screw-Type |
Isolation (V) | 3.750,00 |
Approvals | CCC, CE, ENEC, UL |
