FKC12-24D05 MEANWELL DC-DC converter for PCB mount, Input: 18-36VDC. Dual Output: -5 / +5VDC. Power: 12W. I/..
FKC12-24D05
MEANWELL
DC-DC converter for PCB mount, Input: 18-36VDC. Dual Output: -5 / +5VDC. Power: 12W. I/O isolation 1600VDC. DIP
ADAPTERS > AC plug
Brand new product in its original packaging covered by the warranties and certifications provided by MEANWELL
Best sellers
▲More info
▲| Name | FKC12-24D05 |
|---|---|
| Long Description | Dc/DC converter to the printed circuit board in format DIP, with 2 outputs. Metallic box. FormatDIPfor soldering on printed circuit boards. Input range18-36Vcc. Outputs: -5vdc:
+5vdc:
Power:12W. Isolation input-output 1600Vcc. Efficiency typical 83%. Low noise and ripple 85mVp-p. Without the need of minimum load on the output. Working temperature: from-40up+100 ° C. See the curve of drift according to the temperature in the technical data sheet. Max temperature box:+100 ° C. Dimensions (Length x Width x Height) [mm]:31,8 x 20,3 x 10,2. 3 years of warranty. Manufacturer: P-DUKE. The converters of the series FKC12 have a wide input range 2:1 and an isolation between input and output of 1600Vcc. Do not have requirements of minimum load on the output and are protected against overloads and short-circuits. Its metal case improved behavior of temperature at the same time improving the behavior EMI. CE certified and UL listed. |
| Country of Origin | Taiwan |
| Manufacturer | P-DUKE |
| Product type | Dc/DC converters |
| Format | For Printed Circuit |
| Subformato | DIP |
| Applications | Automation of Buildings, Industrial, Instrumentation, Telecommunications |
| Series | FKC12 |
| Warranty (Years) | 3,00 |
| Height (mm) | 10.2 |
| Width (mm) | 20.3 |
| Long/Background | 31.8 |
| Input range | 2:1 |
| Range DC Input | 18, 19, 20,4, 21, 21,6, 22,5, 24, 25,2, 26,4, 28, 28,8, 30, 31,2, 32, 32,4, 33,6, 35, 36 |
| DC input Min | 18,00 |
| DC input Max | 36,00 |
| Input connector | Pin |
| Output 1 | -5 |
| Output 2 | +5 |
| Power (W) | 12,00 |
| Peak Power (W) | Twelve |
| Output connector | Pin |
| Isolation (V) | 1.600,00 |
| Approvals | CE, UL |
