26000302 HITRONIC HRH400 2G 50/125 OM3 LAPP Divisible breakout cable for direct connector assembly J-V(ZN)HH

Benefits

• Suitable for field assembly
• Universal cable for cabling of
  buildings
• Very easy to install due to compact design,
  high flexibility, and small bending radii
• Zero electromagnetic interference as the cable contains no metal (totally dielectric)

Application range

• For indoor use
• Tertiary cabling
• Structured cabling - backbone
• Methods of Deployment: laying in trunking, ducts, trays, empty plastic pipes, building riser, raised floors and plenums

Product features

• Installation cable with up to
  12 Simplex cables
• Outer sheath flame-retardant and halogen-free
• Mechanically robust

Product Make-up

• 2.1 mm tight-buffered sub-cable
  with LSZH sheath (identified by numbers)
• Central GRP strength element
• Aramid yarns as strain relief
• LSZH inner and outer sheaths
• Colour: violet for OM4, aqua (RAL 6027) for OM3, orange (RAL 2003) for OM2 and OM1,
  yellow for Single-mode

Classification ETIM 5

• ETIM 5.0 Class-ID: EC000034
• ETIM 5.0 Class-Description: Fibre optic cable

Classification ETIM 6

• ETIM 6.0 Class-ID: EC000034
• ETIM 6.0 Class-Description: Fibre optic cable

Dimensions

• tight-buffer (secondary coated fibre): 900µm
• sub-cable: 2.1mm

Core identification code

• Sub-cable: with black numbers

Fibre type

• GOF - Glass Optical Fibre

Standard designation

• J-V(ZN)HH

Optical values

• see data sheet

Optical fibre type

• Core material: glass
• Cladding material: glass

Permissible bending radius

• Static: ≥ 15 x outer diameter
• Dynamic: ≥ 20 x outer diameter

Temperature range

• Fixed installation: -20°C to +70°C
