2170456 ETHERLINE ROBUST FR Cat.7 FLEX LAPP ETHERLINE ROBUST FR Cat.7 FLEX

Benefits

• Outstanding weather, ozone and UV resistance together with the wide temperature range enable versatile use for indoor and outdoor applications
• Good resistance to cold and hot water as well as water-soluble cleaning and cooling agents
• Well-suited to steam cleaning

Application range

• For flexible applications
  (7-wire stranded conductor)
• Machine tool building, medical technology, laundries, car washing equipment, chemical industry, composting plants, sewage works
• Food and beverage industry, especially for production and processing equipment of milk and meat products
• for industrial secondary and tertiary cabling according to EN 50173-3
  ISO/IEC 24702
• suitable for EtherCAT and EtherNet/IP applications

Product features

• High-quality, double screening ensures high transmission reliability in areas with electromagnetic interference
• Flame retardance makes it suitable for indoor and outdoor installations
• 2pair: 10/100 Mbit/s for Industrial Ethernet
• 4pair: 100Mbit/s up to 10 Gbit/s for Industrial Ethernet
• Many applications with Industrial Ethernet, e.g. PROFINET type B, i.e. fixed installation and flexible use.

Norm references / Approvals

• UV-resistant according to ISO 4892-2
• Flame-retardant according IEC 60332-1-2
• Ozone-resistant according to EN 50396

Product Make-up

• 7-wire bare stranded copper conductor
• Core insulation: Based on Polyolefin
• Screening: wrapped with braided tinned-copper wires
• Outer sheath made of special TPE
• Colour: black

Classification ETIM 5

• ETIM 5.0/6.0 Class-ID: EC000830
• ETIM 5.0/6.0 Class-Description: Data cable

Classification ETIM 6

• ETIM 6.0 Class-ID: EC000830
• ETIM 6.0 Class-Description: Data cable

Minimum bending radius

• Flexing: 10 x outer diameter
• Fixed installation: 8 x outer diameter

Characteristic impedance

• nom. 100 Ω acc. to IEC 61156-6

Temperature range

• Fixed installation: -50°C to +80°C
• Flexing: -40°C to +80°C
