2170195 UNITRONIC LAN 500 U/FTP Cat.6A LSZH LAPP Ethernet cable for Category 6, class EA, verified up to 500..

Benefits

• LAN cables for structured building cabling according to EN 50173 and ISO/IEC 11801

Application range

• Mainly used where the terminal density is very high, e.g. for wiring office, administration and development buildings in the tertiary area (floor wiring).
• Cable length in tertiary area (horizontal area, floor) should not exceed a length of 100 m in accordance with the ISO/IEC 11801 and EN 50173 standards (90 m in cable duct + 10 m in working area)

Product features

• Transfer of digital and analogue data signals
• Flame retardant acc. to IEC 60332-1-2
  2170195
  2170196: flame retardant acc. to IEC 60332-1-2 and IEC 60332-3-24
• IEEE 802.3: 10/100/1000Base-T, 10GBase-T IEEE 802.5: ISDN; FDDI; ATM

Norm references / Approvals

• Class EA out of the standard ISO/IEC 11801 corresponds to Cat.6A
• LAN Cat.6A cables from Lapp Kabel for "Structured Cabling Systems” meet the requirements in accordance with EIA/TIA-568 and TSB36, as well as ISO/IEC 11801 or EN 50173 (Class EA - permanent link).

Product Make-up

• Solid conductor
• U/FTP: aluminium compound foil as pair screening
• F/FTP: aluminium compound foil as overall screening and pair screening
• S/FTP: copper braid as overall screening and pair screening with aluminium compound foil
• outer sheath either as PVC (color grey RAL1015) or LSZH (color orange RAL2003)

Classification ETIM 5

• ETIM 5.0 Class-ID: EC000830
• ETIM 5.0 Class-Description: Data cable

Classification ETIM 6

• ETIM 6.0 Class-ID: EC000830
• ETIM 6.0 Class-Description: Data cable

Minimum bending radius

• during installation: 8 x outer diameter
• Fixed installation: 4 x outer diameter

Characteristic impedance

• 100 Ω ± 15%

Temperature range

• Fixed installation: -20°C to +60°C
• Flexing: 0°C to +50°C
