0107009 ÖLFLEX HEAT 260 SC 12/19AWG OG LAPP ÖLFLEX HEAT 260 SC 12/19AWG OG
0107009
ÖLFLEX HEAT 260 SC 12/19AWG OG
LAPP
100 m.
ÖLFLEX HEAT 260 SC 12/19AWG OG
ÖLFLEX® HEAT 260 SC
ÖLFLEX HEAT Temperature measurement cables
Brand new product in its original packaging covered by the warranties and certifications provided by LAPP
Best sellers
▲More info
▲ÖLFLEX® HEAT 260 SC - PTFE single core, robust, chemical resistant and space-saving, for use in machine and plant construction at temperatures: -190°C to +260°C
- Excellent chemical, thermal and
electrical performance - Space and weight-saving
- UL AWM Style 11486 (28-12 AWG)
Benefits
- Small outer diameters for maximum saving of space and weight
- Resistant to contact with mostly all highly aggressive chemical media
- Stress crack resistant to frequent ambient temperature fluctuations
Application range
- For use in environments with very high operating temperatures, heavy usage of chemical agents or confined spaces
- Typical fields of application
- Aerospace engineering
- High-frequency engineering
- Control cabinets with high heat
generation
- Measuring instruments
- Furnaces and brickworks
- Heating equipment and kitchen
appliances
- Electric motor building
- Installations in the chemical industry
Product features
- Flame retardance rating (UL): FT2 (Horizontal flame test)
- Flame-retardant according to IEC 60332-1-2 & CSA FT1
- ÖLFLEX® HEAT 260 made of PTFE
- Outstanding resistance against acids,
alkalis, solvents, lacquers, petrol, oils and
many other chemical media
- Difficult to inflame
- High dielectric strength and high abrasion
resistance
- Low water absorption
- Resistant to microbes
- Adhesion-free insulation materials
- Weather and ozone resistant
- Hydrophobic and dirt-repellent
- High elongation and tear resistance
- Resists contact with liquid nitrogen
- Resistant against hydraulic fluids - Silver plated copper is characterized by good surface conductivity (skin effect) and good solderability
Norm references / Approvals
- 28-12 AWG: UL AWM Style 11486 according to UL 758 (File No E63634) & cRU AWM I A/B according to CSA C22.2 No 210 (File No E63634)
Product Make-up
- Silver-plated AWG copper conductor
- PTFE core insulation
- PTFE = Polytetrafluoroethylene
Classification ETIM 5
- ETIM 5.0 Class-ID: EC000993
- ETIM 5.0 Class-Description: Single core cable
Classification ETIM 6
- ETIM 6.0 Class-ID: EC000993
- ETIM 6.0 Class-Description: Single core cable
Conductor stranding
- AWG conductor sizes: 7, 19 or 37 wires
Minimum bending radius
- Fixed installation: 4 x outer diameter
Nominal voltage
- U0/U: 300/500 V
Test voltage
- 3400 V
Temperature range
- Fixed installation: -190°C to +260°C
- UL/CSA: up to +200°C
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE LAPP EN.pdf | 69 Mbytes |
|
| 0107009 ÖLFLEX HEAT 260 SC 12/19AWG OG 0107009 EN_0103104.pdf | 363 Kbytes |
|
