0106002 ÖLFLEX HEAT 260 SC 14/19 AWG BU LAPP PTFE single core, robust, chemical resistant

Benefits

• Small outer diameters for maximum saving of space and weight
• Resistant to contact with mostly all highly aggressive chemical media
• Stress crack resistant to frequent ambient temperature fluctuations

Application range

• For use in environments with very high operating temperatures, heavy usage of chemical agents or confined spaces
• Typical fields of application
  - Aerospace engineering
  - High-frequency engineering
  - Control cabinets with high heat
  generation
  - Measuring instruments
  - Furnaces and brickworks
  - Heating equipment and kitchen
  appliances
  - Electric motor building
  - Installations in the chemical industry

Product features

• Flame retardance rating (UL): FT2 (Horizontal flame test)
• Flame-retardant according to IEC 60332-1-2 & CSA FT1
• ÖLFLEX® HEAT 260 made of PTFE
  - Outstanding resistance against acids,
  alkalis, solvents, lacquers, petrol, oils and
  many other chemical media
  - Difficult to inflame
  - High dielectric strength and high abrasion
  resistance
  - Low water absorption
  - Resistant to microbes
  - Adhesion-free insulation materials
  - Weather and ozone resistant
  - Hydrophobic and dirt-repellent
  - High elongation and tear resistance
  - Resists contact with liquid nitrogen
  - Resistant against hydraulic fluids
• Silver plated copper is characterized by good surface conductivity (skin effect) and good solderability

Norm references / Approvals

• 28-12 AWG: UL AWM Style 11486 according to UL 758 (File No E63634) & cRU AWM I A/B according to CSA C22.2 No 210 (File No E63634)

Product Make-up

• Silver-plated AWG copper conductor
• PTFE core insulation
• PTFE = Polytetrafluoroethylene

Classification ETIM 5

• ETIM 5.0 Class-ID: EC000993
• ETIM 5.0 Class-Description: Single core cable

Classification ETIM 6

• ETIM 6.0 Class-ID: EC000993
• ETIM 6.0 Class-Description: Single core cable

Conductor stranding

• AWG conductor sizes: 7, 19 or 37 wires

Minimum bending radius

• Fixed installation: 4 x outer diameter

Nominal voltage

• U0/U: 300/500 V

Test voltage

• 3400 V

Temperature range

• Fixed installation: -190°C to +260°C
• UL/CSA: up to +200°C
