RS2-02-C3 177286 Y7-177286 EATON ELECTRIC Safety switch magnetic Lateral Cable 3 m 2 NC
RS2-02-C3
177286
Y7-177286
EATON-MOELLER
Safety switch magnetic; Lateral; Cable 3 m; 2 NC
RS2-02-C3
Eaton Moeller® series RS Safety switch, RS, 2 NC, Reed contacts, Ue 24 V DC, -10 - +55 °C, Plastic, 3 m connection cable, Sn 8 - 19 mm
Non-contacting safety switch, switching distance according to IEC 60947-5-2, SL up to Ple ISO 13849, SL up zo SIL3 according to IEC 62061, 2NC, 3m cable
Sensors > Position switch with separate actuator
Position Switches
Brand new product in its original packaging covered by the warranties and certifications provided by EATON-MOELLER
Related products
▲Best sellers
▲More info
▲General specifications
Product Name
Eaton Moeller® series RS Safety switch
Catalog Number
177286
Model Code
RS2-02-C3
EAN
4015081717392
Product Length/Depth
52 mm
Product Height
13 mm
Product Width
26 mm
Product Weight
0.182 kg
Certifications
UL
UL Category Control No.: NRKH, NRKH7
CSA File No.: UL report applies to both US and Canada
IEC 62061
CE
EN ISO 13849
UL File No.: E166051
Certified by UL for use in Canada
ISO 14119
UL Category Control No.: NRKH, NRKH7
CSA File No.: UL report applies to both US and Canada
IEC 62061
CE
EN ISO 13849
UL File No.: E166051
Certified by UL for use in Canada
ISO 14119
Catalog Notes
Reed contacts
Features & Functions
Electric connection type
With cable preassembled
Enclosure material
Plastic
Material
Plastic
General
Connection type
3 m connection cable
Degree of protection
IP67
NEMA Other
NEMA Other
Product category
Non-contacting safety switch
Rated switching distance (Sn) - min
8 mm
Rated switching distance (Sn) - max
19 mm
Repetition accuracy
≤ 10 % (deviation)
Suitable for
Safety functions
Type
Safety position switch
Ambient conditions, mechanical
Mounting position
As required
Shock resistance
30 g, Shock duration 11 ms, Half-Sinusoidal
Vibration resistance
0 - 2000 Hz, 1 mm
Climatic environmental conditions
Ambient operating temperature - min
-10 °C
Ambient operating temperature - max
55 °C
Relative humidity
90 % (at 55 °C)
Terminal capacities
Terminal capacity (AWG)
22
Electrical rating
Rated operational current (Ie) at AC-15, 220 V, 230 V, 240 V
0 A
Rated operational current (Ie) at AC-15, 24 V
0 A
Rated operational current (Ie) at DC-13, 125 V
0 A
Rated operational current (Ie) at DC-13, 220 V, 230 V
0 A
Rated operational current (Ie) at DC-13, 24 V
0.3 A
Rated operational voltage
24 V DC
Contacts
Number of contacts (change-over contacts)
0
Number of contacts (normally closed contacts)
2
Number of contacts (normally open contacts)
0
Safety
Explosion safety category for gas
None
Explosion safety category for dust
None
Safety parameter (EN ISO 13849-1)
20,000,000 switching cycles, B10d
PL e, Performance level
PL e, Performance level
Safety parameter (IEC 62061)
SIL: 3
Design verification
Equipment heat dissipation, current-dependent Pvid
0 W
Heat dissipation capacity Pdiss
0 W
10.2.2 Corrosion resistance
Meets the product standard's requirements.
10.2.3.1 Verification of thermal stability of enclosures
Meets the product standard's requirements.
10.2.3.2 Verification of resistance of insulating materials to normal heat
Meets the product standard's requirements.
10.2.3.3 Resist. of insul. mat. to abnormal heat/fire by internal elect. effects
Meets the product standard's requirements.
10.2.4 Resistance to ultra-violet (UV) radiation
Meets the product standard's requirements.
10.2.5 Lifting
Does not apply, since the entire switchgear needs to be evaluated.
10.2.6 Mechanical impact
Does not apply, since the entire switchgear needs to be evaluated.
10.2.7 Inscriptions
Meets the product standard's requirements.
10.3 Degree of protection of assemblies
Does not apply, since the entire switchgear needs to be evaluated.
10.4 Clearances and creepage distances
Meets the product standard's requirements.
10.5 Protection against electric shock
Does not apply, since the entire switchgear needs to be evaluated.
10.6 Incorporation of switching devices and components
Does not apply, since the entire switchgear needs to be evaluated.
10.7 Internal electrical circuits and connections
Is the panel builder's responsibility.
10.8 Connections for external conductors
Is the panel builder's responsibility.
10.9.2 Power-frequency electric strength
Is the panel builder's responsibility.
10.9.3 Impulse withstand voltage
Is the panel builder's responsibility.
10.9.4 Testing of enclosures made of insulating material
Is the panel builder's responsibility.
10.10 Temperature rise
The panel builder is responsible for the temperature rise calculation. Eaton will provide heat dissipation data for the devices.
10.11 Short-circuit rating
Is the panel builder's responsibility. The specifications for the switchgear must be observed.
10.12 Electromagnetic compatibility
Is the panel builder's responsibility. The specifications for the switchgear must be observed.
10.13 Mechanical function
The device meets the requirements, provided the information in the instruction leaflet (IL) is observed.
| Feature Name | Feature Value |
|---|---|
| With status indication (EF001602) | No |
| Suitable for safety functions (EF001597) | Yes |
| Width sensor (EF007094) | 26 mm |
| Height of sensor (EF007283) | 13 mm |
| Length of sensor (EF007334) | 52 mm |
| Forced opening (EF006694) | No |
| Number of safety auxiliary contacts (EF006940) | 2 |
| Number of contacts as normally closed contact (EF008255) | 2 |
| Number of contacts as normally open contact (EF008256) | 0 |
| Number of contacts as change-over contact (EF008257) | 0 |
| Type of switching contact (EF003591) | Other |
| Rated operation current Ie at AC-15, 24 V (EF007084) | 0 A |
| Rated operation current Ie at AC-15, 125 V (EF007082) | 0 A |
| Rated operation current Ie at AC-15, 230 V (EF001385) | 0 A |
| Rated operation current Ie at DC-13, 24 V (EF007087) | 0.3 A |
| Rated operation current Ie at DC-13, 125 V (EF007085) | 0 A |
| Rated operation current Ie at DC-13, 230 V (EF001386) | 0 A |
| Construction type housing (EF004008) | Cuboid |
| Housing material (EF001596) | Plastic |
| Coating housing (EF001601) | Plastic-coated |
| Type of interface (EF006977) | None |
| Type of interface for safety communication (EF003956) | None |
| Type of electric connection (EF003961) | With cable preassembled |
| Explosion safety category for gas (EF003997) | None |
| Explosion safety category for dust (EF003998) | None |
| Ambient temperature during operating (EF007515) | -10 °C |
| Degree of protection (IP) (EF005474) | IP67 |
| Degree of protection (NEMA) (EF011959) | Other |
