> EATON - MOELLER>Circuit Breakers NZM >NZM3-4-XKSAV 132675 Y7-132675 ELECTRIC Cover, 4p, for connection width extension
ANUNCIAR
Previous Product Next Product
NZM3-4-XKSAV 132675 Y7-132675 EATON ELECTRIC Cover, 4p, for connection width extension View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

NZM3-4-XKSAV 132675 Y7-132675 EATON ELECTRIC Cover, 4p, for connection width extension

NZM3-4-XKSAV

132675

Y7-132675

EATON-MOELLER

Cover, 4p, for connection width extension

NZM3-4-XKSAV

Eaton Moeller series NZM - Molded Case Circuit Breaker. Cover, 4p, for connection width extension, NZM3

Optional accessories for the circuit-breaker series NZM offers a comprehensive portfolio of application options for use world wide. The mounting is always flexible and easy thanks to the modular function groups. Notes: part no. contains parts for a terminal located at top or bottom for 3 or 4 pole switches. Insulation/protection against direct contact where cable lugs, busbars or tunnel terminals are used. Included in the set with tunnel terminals. when using insulated conductor material to IP1X. Can be used for: NZM3-4, PN3-4, N(S)3-4, NZM3-4-XKV70(-2)

More details


Low-voltage industrial components > Phase separation plate for power circuit breaker

Circuit Breakers NZM

Brand new product in its original packaging covered by the warranties and certifications provided by EATON-MOELLER

Total: $155.31
Unit price: $155.31
This price is per unit and is the net value (not including taxes if applicable).

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


General specifications

Product Name
Eaton Moeller series NZM connection type NA
Catalog Number
132675
Model Code
NZM3-4-XKSAV
EAN
4015081296132
Product Length/Depth
280 mm
Product Height
120 mm
Product Width
230 mm
Product Weight
0.48 kg
Compliances
IEC
RoHS conform

Product specifications

Used with
NZM3-4-XKV70(-2)
NZM3-4, PN3-4, N(S)3-4
Type
AccessoryTerminalTerminal cover
10.10 Temperature rise
The panel builder is responsible for the temperature rise calculation. Eaton will provide heat dissipation data for the devices.
10.11 Short-circuit rating
Is the panel builder's responsibility. The specifications for the switchgear must be observed.
10.12 Electromagnetic compatibility
Is the panel builder's responsibility. The specifications for the switchgear must be observed.
10.13 Mechanical function
The device meets the requirements, provided the information in the instruction leaflet (IL) is observed.
10.2.2 Corrosion resistance
Meets the product standard's requirements.
10.2.3.1 Verification of thermal stability of enclosures
Meets the product standard's requirements.
10.2.3.2 Verification of resistance of insulating materials to normal heat
Meets the product standard's requirements.
10.2.3.3 Resist. of insul. mat. to abnormal heat/fire by internal elect. effects
Meets the product standard's requirements.
10.2.4 Resistance to ultra-violet (UV) radiation
Meets the product standard's requirements.
10.2.5 Lifting
Does not apply, since the entire switchgear needs to be evaluated.
10.2.6 Mechanical impact
Does not apply, since the entire switchgear needs to be evaluated.
10.2.7 Inscriptions
Meets the product standard's requirements.
10.3 Degree of protection of assemblies
Does not apply, since the entire switchgear needs to be evaluated.
10.4 Clearances and creepage distances
Meets the product standard's requirements.
10.5 Protection against electric shock
Does not apply, since the entire switchgear needs to be evaluated.
10.6 Incorporation of switching devices and components
Does not apply, since the entire switchgear needs to be evaluated.
10.7 Internal electrical circuits and connections
Is the panel builder's responsibility.
10.8 Connections for external conductors
Is the panel builder's responsibility.
10.9.2 Power-frequency electric strength
Is the panel builder's responsibility.
10.9.3 Impulse withstand voltage
Is the panel builder's responsibility.
10.9.4 Testing of enclosures made of insulating material
Is the panel builder's responsibility.
Frame
NZM3
Number of poles
Four-pole
Phase separator type
Other

Datasheet - PDF

▲
Title: Size: Type:
PDF CATALOGUE EATON EN .pdf 38 Mbytes
NZM3-4-XKSAV Y7-132675 132675 EN_132675.pdf 1 Mbytes NZM3-4-XKSAV Y7-132675 132675 EN_132675.pdf
