FRBM6-B2/1N/003 178105 Y7-178105 EATON ELECTRIC RCD/MCB combination switch, 2A, 30mA, miniature circuit-brea..
FRBM6-B2/1N/003
178105
Y7-178105
EATON-MOELLER
RCD/MCB combination switch, 2A, 30mA, miniature circuit-breaker type B trip characteristic, 1pole+N, residual current circuit-breaker trip characteristic: AC
FRBM6-B2/1N/003
Eaton Moeller series xEffect - FRBm6/M RCBO - residual-current circuit breaker with overcurrent protection. RCD/MCB combination, 2A, 30mA, MCB B trip char., 1pole+N, RCCB trip char.: AC
High-quality residual current device/miniature circuit breaker combination, line voltage-independent, contact position indicator red - green, terminal rear plug protection, tri-stable slide catch - enables removal from existing busbar system, comprehensive range of accessories suitable for subsequent installation, wide range of rated fault currents, rated operational currents up to 40 A, tripping characteristics B, C, D, rated breaking capacity 6 kA, suitable for outdoor use (on-site power and outdoor distribution board) up to -25 °C
Circuit breakers and fuses > Earth leakage circuit breaker
Modular Switchgear – Tertiary and Differential
Brand new product in its original packaging covered by the warranties and certifications provided by EATON-MOELLER
Best sellers
▲More info
▲General specifications
RoHS conform
Delivery programme
Technical data - electrical
Technical data - mechanical
Design verification as per IEC/EN 61439 - technical data
| Feature Name | Feature Value |
|---|---|
| Number of poles (total) (EF008618) | 2 |
| Number of protected poles (EF005548) | 1 |
| Rated voltage (EF000228) | 240 V |
| Rated insulation voltage Ui (EF001366) | 500 V |
| Rated impulse withstand voltage Uimp (EF011980) | 4 kV |
| Rated current (EF000227) | 2 A |
| Rated fault current (EF002358) | 0.03 A |
| Leakage current type (EF002560) | AC |
| Current limiting class (EF002568) | 3 |
| Rated short-circuit breaking capacity according to EN 61009 (EF012628) | 6 kA |
| Rated short-circuit breaking capacity according to IEC 60947-2 (EF006065) | 0 kA |
| Rated short-circuit breaking capacity Icn according to EN 61009-1 (EF011981) | 6 kA |
| Disconnection characteristic (EF012587) | Undelayed |
| Surge current capacity (EF002564) | 0.25 kA |
| Voltage type (EF000187) | AC |
| Frequency (EF005455) | 50 Hz |
| Release characteristic (EF000889) | B |
| Concurrently switching neutral conductor (EF005997) | Yes |
| With interlocking device (EF007385) | No |
| Over voltage category (EF002569) | 3 |
| Pollution degree (EF002570) | 2 |
| Ambient temperature during operating (EF007515) | -25 °C |
| Width in number of modular spacings (EF002950) | 2 |
| Built-in depth (EF000218) | 75.5 mm |
| Anti-nuisance tripping version (EF009497) | No |
| Degree of protection (IP) (EF005474) | IP20 |
| Connectable conductor cross section solid-core (EF007337) | 1 mm² |
| Connectable conductor cross section multi-wired (EF007343) | 1 mm² |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF EATON XEFFECT SWITCHGEAR RANGE EN.pdf | 8 Mbytes |
|
| PDF CATALOGUE EATON EN .pdf | 38 Mbytes |
|
| FRBM6-B2/1N/003 Y7-178105 178105 EN_243133.pdf | 551 Kbytes |
|
