EME3P63BMODBUSMID 167410 EATON ELECTRIC Power meter, 3 N, 63 A, MODBUS, MID
EME3P63BMODBUSMID
167410
EATON-MOELLER
Power meter, 3 N, 63 A, MODBUS, MID
63A MODB MID Energy Meter
Digital real power meter with partial real power meter that can be set to zero and featuring integrated Modbus RTU communication - 2 tariffs, real power meter with real power partial meter for direct connection 0.25-5 (63) A, and integrated Modbus RTU communications - 2 tariffs, for direct connection up to 63 A, display with 9 numbers for showing 8 power registers, wrong connection signal (phase mix-up and phase failure), accuracy class 1 for real power and power as per EN 50470-3 (B), perfect operating current range (Ist ... Imax), for direct connection 63 A = 0.015 ... 63 A, power register can be set to zero (not on MID type) , “Partial” power register can be set to zero in MID type as well, sealable terminal covers, power register for input and output
Meters > Kilowatt-hour meter
Modular Switchgear – Industrial
Brand new product in its original packaging covered by the warranties and certifications provided by EATON-MOELLER
Best sellers
▲More info
▲Technical data ETIM 7.0
| Feature Name | Feature Value |
|---|---|
| Type of meter (EF005441) | Electromechanical |
| Nominal current (In) (EF008873) | 80 A |
| Max. current (Imax) (EF000877) | 80 A |
| Nominal voltage (Un) N-L (EF008871) | 184 V |
| Nominal voltage (Un) L-L (EF008872) | 319 V |
| Frequency (EF000416) | 50 Hz |
| Accuracy class (EF008842) | B |
| Pole type (EF008843) | Three conductor |
| Model (EF000010) | Direct measurement |
| Energy type (EF007135) | Effective power |
| Suitable for (EF000073) | Purchase/supply |
| Tariff type (EF007550) | Two-tariff |
| Tariff control (EF008834) | Internal |
| Measurement type load profile (EF008844) | No |
| Escapement mechanism (EF008835) | No |
| Calibrated (EF008836) | Yes |
| Approval (EF008837) | Measuring Instruments Directive |
| Pulse output (EF008838) | Electrical |
| Pulse type (EF008839) | S0 |
| Pulse rate (EF008840) | 0 Imp/kWh (kvarh) |
| Type of indication (EF000306) | Digital |
| Mounting method (EF000003) | DRA (DIN-rail adapter) |
| Width in number of modular spacings (EF002950) | 4.1 |
| Width (EF000008) | 72 mm |
| Depth (EF000049) | 90 mm |
| Height (EF000040) | 64 mm |
| Type of interface (EF006977) | Other |
| EEC40 signature (EF008845) | No |
| With lock code (EF008846) | Yes |
| Number of positions total (counter) (EF004442) | 9 |
| Degree of protection (IP) (EF005474) | IP20 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF EATON XEFFECT SWITCHGEAR RANGE EN.pdf | 8 Mbytes |
|
| PDF CATALOGUE EATON EN .pdf | 38 Mbytes |
|
| EME3P63BMODBUSMID EME3P63BMODBUSMID 167410 167410_EN.pdf | 152 Kbytes |
|
