C22-PVT45P-K02 121611 Y7-121611 EATON ELECTRIC Emergency-stop, 45mm, pull/turn release, 2N/C, black
C22-PVT45P-K02
121611
Y7-121611
EATON-MOELLER
Emergency-stop, 45mm, pull/turn release, 2N/C, black
C22-PVT45P-K02
Eaton Moeller® series C22 Emergency-stop, Palm-tree shape, 45 mm, Turn-to-release function, 2 NC, Screw connection
Emergency-stop, Product range: RMQ Compact, Complete unit, Design: Palm-tree shape, Diameter: 45 mm, Illumination: Non-illuminated, Turn-to-release function, Connection type: Screw connection, Description: Tamper-proof according to ISO 13850/EN 418, Color Mushroom head: Red, Color Base: yellow, Red mushroom head (RAL 3000), Degree of Protection: IP66, IP67, IP69K, Connection to SmartWire-DT: no, Contacts N/C = Normally closed: 2 NC, Contacts Notes: = safety function, by positive opening to IEC/EN 60947-5-1, Actuator travel and actuation force as per DIN EN 60947-5-1, K.5.4.1: mm 4.65, Maximum travel: mm 5.7 , Minimum force for positive opening: N 30, Function: Turn-to-release function, Standards: IEC/EN 60947-5-5, VDE 0660
Low-voltage industrial components > Emergency stop complete
Auxiliary Control and Signalling Elements
Brand new product in its original packaging covered by the warranties and certifications provided by EATON-MOELLER
Best sellers
▲More info
▲General specifications
Features & Functions
General
NEMA 4X, 13
Electrical rating
Contacts
| Feature Name | Feature Value |
|---|---|
| Unlocking method (EF001403) | Turn-release |
| Number of contacts as normally closed contact (EF008255) | 2 |
| Number of contacts as normally open contact (EF008256) | 0 |
| Degree of protection (IP) (EF005474) | IP67/IP69K |
| Degree of protection (NEMA) (EF011959) | 4X, 13 |
| Mounting method (EF000003) | Built-in |
| With lighting (EF003829) | No |
| Supply voltage lamp (EF006522) | 0 V |
| Hole diameter (EF000079) | 22.5 mm |
| Connection type auxiliary circuit (EF006820) | Other |
| Diameter cap (EF001423) | 45 mm |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF EATON COMMAND INDICATION EN.pdf | 24 Mbytes |
|
| PDF CATALOGUE EATON EN .pdf | 38 Mbytes |
|
| C22-PVT45P-K02 Y7-121611 121611 PT_121647.pdf | 3 Mbytes |
|
