003Z3921 DANFOSS REFRIGERATION RA-HC, DN 25, Without test plugs, Internal thread
003Z3921
DANFOSS REFRIGERATION
RA-HC, DN 25, Without test plugs, Internal thread
Home > DANFOSS REFRIGERATION
Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS REFRIGERATION
Best sellers
▲More info
▲RA-HC DN 25, Internal thread, without test plugs, control valve
Product details
| Gross weight | 0.52 Kilogram |
| Net weight | 0.534 Kilogram |
| Volume | 0.566 Liter |
| EAN | 5702420117386 |
| Type | RA-HC |
| Product group | Other valves |
| Gross weight | 0.52 Kilogram |
| Net weight | 0.534 Kilogram |
| Volume | 0.566 Liter |
| EAN | 5702420117386 |
| Type | RA-HC |
| Product group | Other valves |
| China RoHS compliance | Yes with exemptions |
| China RoHS exemption clause | 7.3 |
| Connection types | Internal thread |
| Contains batteries | No |
| Description | RA-HC DN 25, Internal thread, without test plugs, control valve |
| Differential pressure range [bar] [Max] | 1 bar |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(c) |
| Kvs values [m³/h] | 5.5 m³/h |
| Media temperature [°C] [Max] | 100 °C |
| Media temperature [°C] [Min] | -10 °C |
| Pressure class | PN 16 |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Test plugs | Without test plugs |
| Valve body material | DZR brass |
| Valve size | DN 25 |
| China RoHS compliance | Yes with exemptions |
| China RoHS exemption clause | 7.3 |
| Connection types | Internal thread |
| Contains batteries | No |
| Description | RA-HC DN 25, Internal thread, without test plugs, control valve |
| Differential pressure range [bar] [Max] | 1 bar |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(c) |
| Kvs values [m³/h] | 5.5 m³/h |
| Media temperature [°C] [Max] | 100 °C |
| Media temperature [°C] [Min] | -10 °C |
| Pressure class | PN 16 |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Test plugs | Without test plugs |
| Valve body material | DZR brass |
| Valve size | DN 25 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE DANFOSS REFRIGERATION AND AIRCONDITIONING EN.pdf | 11 Mbytes |
|
| 003Z3921 003Z3921 ES_003Z3931.pdf | 969 Kbytes |
|
