EM28072DMV63XOSX CARLO GAVAZZI Function: Energy analyzer , Mounting: DIN-rail and Panel , Power supply: Self.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

EM28072DMV63XOSX CARLO GAVAZZI Function: Energy analyzer , Mounting: DIN-rail and Panel , Power supply: Self..

EM28072DMV63XOSX

CARLO GAVAZZI

Function: Energy analyzer , Mounting: DIN-rail and Panel , Power supply: Self power supply, Output digital input: Dual static output (opto-mosfet) and serial port, Input type: 3-phase AC , Connection: CT/VT, Communication: None , Range: 120VLN/230VLL CA, Display: 6+1 DGT , Variables: kWh, kvarh, V, A, W, Digital inputs: None, Pulse: 2, Alarms: None, Analogue: none

Compact three-phase multichannel power analyzer, Measurement 2 three-phase or 6 single-phase loads

Three-phase Energy analyzer, 160 to 240 V L-N, 277 to 415 V L-L, 32 (36) A, RS485 Modbus RTU Pulse output

More details


Controls > Digital Panel Meters and temperature

* Brand new product in its original packaging covered by the warranties and certifications provided by CARLO GAVAZZI

Total price: $281.32
Unit price: $281.32

*This price is per unit and is the net value (not including taxes if applicable).

If our price is not the best, please ask us for a quote. Ask for a quotation

More info

▲


Specifications

Voltage inputs
1-phase (2-wire), 115 V L-N; 1-phase (2-wire), 120 V L-N; 3-phase (4-wire), 120/208 V; 3-phase (4-wire), 127/220 V
Frequency
50Hz; 60Hz
Current inputs
direct connection up to 32 A
Multi-load sensor type
solid core; split core
Monitored loads per meter
1-phase loads: up to 6; 3-phase loads: up to 2
Energy metering
Consumption; Consumption and generation
Static output
Pulse
Communication port and protocol
RS485 (Modbus RTU)
Power supply
Self power supply
Approvals, marks, declarations
CE (Europe); cULus (North America); UKCA (UK)

Datasheet - PDF

▲
Title: Size: Type:
EM28072DMV63XOSX EM28072DMV63XOSX EN_EM28072DMV63X2SN.pdf 3 Mbytes EM28072DMV63XOSX EM28072DMV63XOSX EN_EM28072DMV63X2SN.pdf
Download general catalog Download general catalog
