EM28072DMV53X2SN CARLO GAVAZZI Function: Energy analyzer , Mounting: DIN-rail and Panel , Power supply: Self.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

EM28072DMV53X2SN CARLO GAVAZZI Function: Energy analyzer , Mounting: DIN-rail and Panel , Power supply: Self..

EM28072DMV53X2SN

CARLO GAVAZZI

Function: Energy analyzer , Mounting: DIN-rail and Panel , Power supply: Self power supply, Output digital input: None, Input type: 3-phase AC , Connection: CT/VT, Communication: Dual RS485 serial communication port, Range: 230VLN/400VLL AC, Display: 6+1 DGT , Variables: kWh, kvarh, V, A, W, Digital inputs: None, Pulse: None, Alarms: None, Analogue: none

Compact three-phase multichannel power analyzer, Measurement 2 three-phase or 6 single-phase loads

Three-phase Energy analyzer, 160 to 240 V L-N, 277 to 415 V L-L, 32 (36) A, RS485 Modbus RTU

More details


Meters > Kilowatt-hour meter

Controls > Digital Panel Meters and temperature

Brand new product in its original packaging covered by the warranties and certifications provided by CARLO GAVAZZI

* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


Specifications

Voltage inputs
1-phase (2-wire), 220 V L-N; 1-phase (2-wire), 230 V L-N; 1-phase (2-wire), 240 V L-N; 3-phase (3-wire), 380 V L-L; 3-phase (3-wire), 400 V L-L; 3-phase (3-wire), 415 V L-L
Frequency
50Hz; 60Hz
Current inputs
direct connection up to 32 A
Multi-load sensor type
solid core; split core
Monitored loads per meter
1-phase loads: up to 6; 3-phase loads: up to 2
Energy metering
Consumption; Consumption and generation
Communication port and protocol
RS485 (Modbus RTU)
Power supply
Self power supply
Approvals, marks, declarations
CE (Europe); cULus (North America); UKCA (UK)

ETIM for EM28072DMV53X2SN Meters (EC001506)
Feature Name Feature Value
Type of meter (EF005441) Electronic
Nominal voltage (Un) N-L (EF008871) 160 V
Nominal voltage (Un) L-L (EF008872) 277 V
Frequency (EF000416) 50 Hz
Pole type (EF008843) Three conductor/four conductor
Model (EF000010) Measurement transformer
Energy type (EF007135) Effective power and reactive power
Suitable for (EF000073) Purchase/supply
Calibrated (EF008836) Yes
Pulse output (EF008838) Optic
Pulse rate (EF008840) 1 Imp/kWh (kvarh)
Type of indication (EF000306) Digital
Mounting method (EF000003) DRA (DIN-rail adapter)
Width in number of modular spacings (EF002950) 4
Type of interface (EF006977) RS-485
With lock code (EF008846) Yes
Number of positions total (counter) (EF004442) 7
Degree of protection (IP) (EF005474) IP40

Datasheet - PDF

▲
Title: Size: Type:
PDF CATALOG CARLO GAVAZZI EN.pdf 3 Mbytes
EM28072DMV53X2SN EM28072DMV53X2SN EN_EM28072DMV63X2SN.pdf 3 Mbytes EM28072DMV53X2SN EM28072DMV53X2SN EN_EM28072DMV63X2SN.pdf
