TIM 60 BLOCK Isolating Transformer
TIM 60
BLOCK
Isolating Transformer
Isolating Transformer TIM 60
transformers
Brand new product in its original packaging covered by the warranties and certifications provided by BLOCK
Related products
▲Best sellers
▲More info
▲The isolating transformers of the TIM series ensure safe galvanic isolation of the primary circuit from the secondary circuit. The transformers are manufactured according to EN (IEC) 61558-2-4 and have a protection class of IP 20.
›Integrated short-circuit and overload protection
›Dual output coils for series or parallel connection
›Excellent moisture protection and low noise emission thanks to XtraDenseFill resin encapsulation
›Screw terminal connections under cover with strain relief
| Product | Isolating transformer |
| Order number | TIM 60 |
| Series | TIM |
| Power | 60 VA |
| Input | 230 V |
| Output | 2 x 115 V • 0.26 Aac |
| Phases | 1 |
| Frequency range | 50 Hz to 60 Hz |
| Short-Circuit Losses | 9 W |
| No-Load Losses | 3.1 W |
| Short circuit voltage uk | 13.9 % |
| EN Insulation class | A (105°C) |
| Duty Cycle | 100 % |
| Wire material | Copper |
| Efficiency | 83.2 % |
General
| Short circuit proof | conditionally short-circuit proof |
| Switching group | Ii |
| Cooling type | AN |
Environment
| Ambient temperature | -20 °C to 40 °C / -4 °F to 104 °F |
| Max. installation height | 2,000 m / 6,562 ft |
Protection and Safety
| Protection type | IP20 |
| Protection class (prepared) | II |
| Overvoltage category | III |
| Degree of contamination | 2 |
Electrical Connections
| Input terminal | Screw terminal |
| Output terminal | Screw terminal |
Size and Weight
| Width | 77 mm / 3.03 in |
| Height | 90 mm / 3.54 in |
| Depth | 166 mm / 6.54 in |
| Weight | 1.52 kg / 3.351 lbs |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE BLOCK EN.pdf | 62 Mbytes |
|
| TIM 60 TIM 60 EN_TIM 60.pdf | 350 Kbytes |
|
