SIM 200 BLOCK Safety-Isolating Transformers
SIM 200
BLOCK
Safety-Isolating Transformers
Safety-Isolating Transformers SIM 200
Safety isolating transformer
transformers
Brand new product in its original packaging covered by the warranties and certifications provided by BLOCK
Related products
▲Best sellers
▲More info
▲The safety transformers of the SIM series ensure safe galvanic isolation of the primary circuit from the secondary circuit. The transformers are manufactured according to EN (IEC) 61558-2-6 and have a protection class of IP 20. By limiting the output voltage, the transformers are suitable for the construction of SELV and PELV circuits.
›Integrated short-circuit and overload protection
›Dual output coils for series or parallel connection
›Excellent moisture protection and low noise emission thanks to XtraDenseFill resin encapsulation
›Screw terminal connections under cover with strain relief
| Product | Safety isolating transformer |
| Order number | SIM 200 |
| Series | SIM |
| Power | 200 VA |
| Input | 230 V |
| Output | 2 x 12 V • 8.33 Aac |
| Phases | 1 |
| Frequency range | 50 Hz to 60 Hz |
| Short-Circuit Losses | 13 W |
| No-Load Losses | 6.4 W |
| EN Insulation class | A (105°C) |
| Duty Cycle | 100 % |
| Wire material | Copper |
| Efficiency | 91.2 % |
General
| Short circuit proof | conditionally short-circuit proof |
| Switching group | Ii |
| Cooling type | AN |
Environment
| Ambient temperature | -20 °C to 40 °C / -4 °F to 104 °F |
| Max. installation height | 2,000 m / 6,562 ft |
Protection and Safety
| Protection type | IP20 |
| Protection class (prepared) | II |
| Overvoltage category | III |
| Degree of contamination | 2 |
Electrical Connections
| Input terminal | Screw terminal |
| Output terminal | Screw terminal |
Size and Weight
| Width | 223 mm / 8.78 in |
| Height | 97 mm / 3.82 in |
| Depth | 117 mm / 4.61 in |
| Weight | 3.6 kg / 7.937 lbs |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE BLOCK EN.pdf | 62 Mbytes |
|
| SIM 200 SIM 200 EN_SIM 200.pdf | 352 Kbytes |
|
| Download general catalog |
|
