FL 4/9 BLOCK PCB Transformers
FL 4/9
BLOCK
PCB Transformers
PCB Transformers FL 4/9
Low profile transformer, safety isolating transformer
transformers
Brand new product in its original packaging covered by the warranties and certifications provided by BLOCK
Related products
▲Best sellers
▲More info
▲The PCB transformers of the FL series impress with minimal height and maximum power density. With dual input and output coils, the transformers can be configured for series or parallel connections. Mounting is done using screw fastenings in the base plate.
›Safety isolating transformer according to EN (IEC) 61558-2-6
›Minimal size with high performance
›Permanent corrosion protection, high insulation value, and maximum electrical reliability thanks to XtraDenseFill resin encapsulation
›Coil body with 2-chamber technology
›Self-extinguishing encapsulation material
| Product | Low profile transformer, safety isolating transformer |
| Order number | FL 4/9 |
| Series | FL |
| Power | 4 VA |
| Input | 2 x 115 V |
| Output | 2 x 9 V • 0.333 Aac |
| Phases | 1 |
| Frequency range | 50 Hz to 60 Hz |
| No-Load Losses | 1 W |
| Short circuit voltage uk | 36 % |
| EN Insulation class | E (120°C) |
| UL Insulation class | class 105 |
| Duty Cycle | 100 % |
| Wire material | Copper |
| Efficiency | 66 % |
General
| Short circuit proof | not short-circuit proof |
| Switching group | IIii0 |
| Cooling type | AN |
Environment
| Ambient temperature | -20 °C to 40 °C / -4 °F to 104 °F |
| Max. installation height | 2,000 m / 6,562 ft |
Protection and Safety
| Protection type | IP00 |
| Protection class (prepared) | I |
| Overvoltage category | III |
| Degree of contamination | 1 |
Electrical Connections
| Input terminal | Pin |
| Output terminal | Pin |
Size and Weight
| Width | 44 mm / 1.73 in |
| Height | 20 mm / 0.79 in |
| Depth | 53 mm / 2.09 in |
| Weight | 0.144 kg / 0.317 lbs |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE BLOCK EN.pdf | 62 Mbytes |
|
| FL 4/9 FL 4/9 EN_FL 4_9.pdf | 328 Kbytes |
|
