1SDA068174R1 ABB XT4S250 PART OF INTERRUPTION 3P F F
1SDA068174R1
ABB
XT4S250 PART OF INTERRUPTION 3P F F
XT4S250 3P F F INTERRUPT PART
XT4S 250 BREAKING PART 3p F F
Low-voltage industrial components > Power circuit-breaker for trafo/generator/installation protection
Molded Case Circuit Breakers ≤ 250 A Xtmax
Brand new product in its original packaging covered by the warranties and certifications provided by ABB
Best sellers
▲More info
▲| ABB EcoSolutions | |
|---|---|
| ABB EcoSolutions | Yes |
| Circular Value | |
| Circular Design Principles Recyclability Rate | Design for Closing Resource Loops - Standard EN45555 - 56.30 % |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| End of Life Instructions | 9AKK108468A2351 |
| Group Waste to Landfill Target | UL 2799 Zero Waste To Landfill Validation available |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| Eco Transparency | |
| Environmental Product Declaration - EPD | 9AKK108469A1857 |
| 9AKK108468A1892 | |
| Environmental | |
| Environmental Information | 9AKK108467A6707 |
| REACH Declaration | 9AKK108466A1425 |
| RoHS Information | 9AKK108466A1424 |
| RoHS Status | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| SCIP | db19ab00-75ae-4c1a-8aa7-9cefa598a266 Italy (IT) |
| Simplified SCIP | 0f3c9348-dbbc-4615-a185-c7d3bbc6fc5e Spain (ES) |
| cccc5300-f795-4eb0-88af-021fbcff19e9 Belgium (BE) | |
| 9fe15bb1-ed57-4ce0-8693-46fa6431c0ba Hungary (HU) | |
| 3502fe89-21ed-4de4-a718-05715b523045 France (FR) | |
| 30c295a4-bed2-471e-a0c3-f79bc223b969 Germany (DE) | |
| 105f2f5f-13a2-47fa-b468-1d31cf254bb1 Germany (DE) | |
| 718e5068-0521-4dbf-b1de-919cafc715f1 Denmark (DK) | |
| 01839e59-6d97-4555-b5e3-52bf5c7003db Sweden (SE) | |
| afd14098-82bd-4b4f-80a9-0d5d4382dd61 Czech Republic (CZ) | |
| a24a047e-bce7-4592-bb83-c68ce5c5ae07 Croatia (HR) | |
| 5afe3a79-768e-415c-b9c4-9436e2b4c694 Germany (DE) | |
| 37441f36-9439-43d5-87d7-24d0e338fdae Poland (PL) | |
| e78e0fb1-3fff-4ea5-abe0-c97f0be3f138 Estonia (EE) | |
| d5bbe48a-dfbe-418f-b2d3-f54fcab67262 Belgium (BE) | |
| a0ef6336-25c0-4fcb-80fa-eaab3187f619 Finland (FI) | |
| ee6625d8-026a-4566-b808-ebf72a33c401 Hungary (HU) | |
| f924a4ce-ff75-43a9-9ddf-89e8fbd8bba8 France (FR) | |
| 526fc212-551d-42d2-b090-98d2c20e7397 Germany (DE) | |
| 1e147977-91f0-4aa1-b7d4-729538030b54 Greece (GR) | |
| c8c11288-edd7-4356-9608-85fd7739fd3a Portugal (PT) | |
| 1cd3df15-6fd7-44f4-8ddd-5728948e2bbf Netherlands (NL) | |
| 3c2ce795-bc38-401e-9625-f5fce24eaa1f Poland (PL) | |
| 316d3f21-ec27-456e-854f-1e47bc420e03 Bulgaria (BG) | |
| 3b547a02-0daa-487a-9eb2-f08ce7460767 Poland (PL) | |
| 8701e82e-91db-4da3-8d97-f9269347500c Sweden (SE) | |
| 0c4f95ee-703e-4a1a-925f-6f88799b4b74 Norway (NO) | |
| 55f403ee-8292-4da5-8e2f-eb1a9e087b6c Germany (DE) | |
| Ordering | |
| E-Number (Finland) | 3641074 |
| EAN | 8015644020712 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85362090 |
| Dimensions | |
| Product Net Width | 105 mm |
| Product Net Height | 160 mm |
| Product Net Depth / Length | 82.5 mm |
| Product Net Weight | 1.82 kg |
| Container Information | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 171 mm |
| Package Level 1 Height | 215 mm |
| Package Level 1 Depth / Length | 151 mm |
| Package Level 1 Gross Weight | 1.916 kg |
| Package Level 1 EAN | 8015644020712 |
| Additional Information | |
| Electrical Durability | 120 cycles per hour |
| 8000 cycle | |
| Mechanical Durability | 240 cycles per hour |
| 25000 cycle | |
| Number of Poles | 3 |
| Opening Time | CB with SOR 15 ms |
| CB with UVR 15 ms | |
| Order Multiple | 1 piece |
| Product Main Type | SACE Tmax XT |
| Product Name | Moulded Case Circuit Breaker |
| Product Type | Breaking Part |
| Rated Frequency (f) | 50 / 60 Hz |
| Rated Voltage (Ur) | 690 V |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Operational Voltage | 690 V AC |
| 500 V DC | |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (220 V AC) 85 kA |
| (230 V AC) 85 kA | |
| (240 V AC) 85 kA | |
| (380 V AC) 50 kA | |
| (415 V AC) 50 kA | |
| (440 V AC) 50 kA | |
| (500 V AC) 36 kA | |
| (525 V AC) 25 kA | |
| (690 V AC) 12 kA | |
| (250 V DC) 2 Poles in Series 50 kA | |
| (500 V DC) 2 Poles in Series 50 kA | |
| (500 V DC) 3 Poles in Series 50 kA | |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (220 V AC) 85 kA |
| (230 V AC) 85 kA | |
| (240 V AC) 85 kA | |
| (380 V AC) 50 kA | |
| (415 V AC) 50 kA | |
| (440 V AC) 50 kA | |
| (500 V AC) 36 kA | |
| (525 V AC) 25 kA | |
| (690 V AC) 12 kA | |
| (250 V DC) 2 Poles in Series 50 kA | |
| (500 V DC) 2 Poles in Series 50 kA | |
| (500 V DC) 3 Poles in Series 50 kA | |
| Rated Uninterrupted Current (Iu) | 250 A |
| Short-Circuit Performance Level | S |
| Standards | IEC60947-2 |
| Sub-type | XT4 |
| Terminal Connection Type | Front |
| Version | F |
| Certificates and Declarations | |
| Data Sheet, Technical Information | 1SDC210100D0206 |
| 1SDC210099D0206 | |
| Declaration of Conformity - CE | 9AKK106713A5529 |
| GL Certificate | 1SDL000163R0095 |
| LR Certificate | 1SDL000163R0100 |
| Instructions and Manuals | 1SDH000722R0001 |
| Classifications | |
| ETIM 7 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| ETIM 8 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| ETIM 9 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| Object Classification Code | Q |
| UNSPSC | 39120000 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370409 |
