1STQ005384B0000 ABB IS2 BLIND DOOR HxWxD1600X800X600
1STQ005384B0000
ABB
IS2 BLIND DOOR HxWxD1600X800X600
IS2 PRE-MONT. BLIND DOOR 1600X800X600
Control and Automation Board W 800 mm H 1600 mm D 600 mm
Cabinet enclosures > Enclosure/switchgear cabinet (empty)
Automation and Control enclosures
Brand new product in its original packaging covered by the warranties and certifications provided by ABB
Best sellers
▲More info
▲| Technical | |
|---|---|
| Suitable For | IS2 Enclosures for Automation |
| Suitable for Product Class | Control and Automation Board |
| Configuration Type | 1. Cabinet with single door |
| Enclosure Type | Pre assembled - cabinet with blind door |
| Product Type | 5B5B10B110 |
| Door Type | Single |
| Door Surface Finishing | Opaque |
| Remarks | ETIM |
| Design | |
| Surface Finishing | Orange Peel, RAL 7035 |
| Material | Pickled steel sheet |
| Door Material | Steel Sheet |
| RAL Number | RAL 7035 - Light Grey |
| Material Compliance | |
| RoHS Declaration | 9AKK108470A5607 |
| RoHS Date | 20250108 |
| REACH Declaration | 9AKK108470A5605 |
| REACH Information | True - contains substances > 0.1 mass percentage |
| REACH Date | 20250108 |
| SCIP | a182fd1a-afc1-43f6-9e37-5b66b8d6718e Italy |
| Simplified SCIP | c9ecc2e5-159c-44d0-adfc-0e3bde8f2148 Germany |
| b5846a0c-f0c9-4a38-acde-76b23600a654 Croatia | |
| 3da0c0e8-93ce-4da0-9428-9ac2382e7c61 Germany | |
| 084801b8-9534-4b1c-a151-ef2949c1e1c2 Hungary | |
| 5e75459a-cb51-445c-8b7a-163eecadedde Netherlands | |
| 9e4a1ea0-d0c7-49b4-9a0d-2a63b490d7de Belgium | |
| 9cb089d0-6aca-48a9-96c9-dc47b282d141 Poland | |
| 6210d8c8-436f-40e7-9d5b-af810116489f Czech Republic | |
| 78d95690-6d97-481c-a53f-ef2be1b25870 Greece | |
| b0e72cf3-b29a-4171-8da6-84e278d9dbd3 Estonia | |
| 3eb10dc3-6ca8-45d0-9219-7d0b044ec554 Sweden | |
| df7ca733-09f7-43ff-8512-9f07036d691d Poland | |
| 658591f1-551d-431d-a528-f6219d2eb9ad France | |
| 7e8c88f2-021c-4c00-b8fa-2572bd464df5 Poland | |
| aaadb941-9c31-41e1-bda8-837a5eec2cf7 Finland | |
| 09879fa4-fe5b-4449-9d0f-83c25ce44bea Norway | |
| fd4a1e30-26b3-4cd4-880e-c92699a1623b Denmark | |
| 1d13348b-d7c7-433a-a1dc-24c39065dfe0 Germany | |
| 8d9c0ff8-f80a-4977-8c03-f11a141e2b5c Germany | |
| ff25506a-ec68-482e-ad68-2a6128914fda Belgium | |
| d3de3e9e-c1a2-4e1c-82ed-7ea505309a77 Germany | |
| 5322bfcc-b99b-4a21-bcd6-3c128f133272 Spain | |
| 490665df-f77b-4e45-97e3-2dd5fd993091 France | |
| 0c0423e8-9ac7-4034-8492-326aa5a4c0ff Portugal | |
| 8583f1fc-22cb-4021-ab4f-d48160052380 Hungary | |
| 371a623a-6eee-447f-8986-c407923a7bc4 Sweden | |
| a18d02be-350f-43f8-b455-21f6139bd63a Bulgaria | |
| WEEE Category | Product Not in WEEE Scope |
| Environmental | |
| Degree of Protection | acc. to IEC 60529 IP55 |
| Environmental Information | 1STC804013D0209 |
| Dimensions | |
| Product Net Width | 810 mm |
| Product Net Height | 1705 mm |
| Product Net Depth / Length | 640 mm |
| Product Net Weight | 84.246 kg |
| Reference Depth/Length | 600 mm |
| Reference Height | 1600 mm |
| Reference Width | 800 mm |
| Ordering | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Gross Weight | 84.246 kg |
| Certificates and Declarations | |
| CSA Certificate (Intrinsic Safe) | 1STE000022 |
| Declaration of Conformity - CE | 1STC860113 |
| UL Certificate | 1STE000022 |
| Installation | |
| Instructions and Manuals | 1STM604121R0008 |
| Mounting Type | Pre assembled |
| Popular Downloads | |
| Data Sheet, Technical Information | 1STC804013D0209 |
| External Classifications and Standards | |
| ETIM 9 | EC000261 - Enclosure/cabinet (empty) |
| ETIM 10 | EC000261 - Enclosure/cabinet (empty) |
| eClass | V11.1 : 27180101 |
| Object Classification Code | U |
| Standards | NEMA 1, 12 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE ABB GENERAL ENCLOSURES 2024 EN.pdf | 138 Mbytes |
|
| PDF CATALOGUE ABB IS2 ENCLOSURES 2024 EN.pdf | 45 Mbytes |
|
| PDF CATALOGUE ABB IS2 ENCLOSURES EN.pdf | 32 Mbytes |
|
