1SDA068295R1 ABB XT4S160 PART OF 4P F F INTERRUPTION
1SDA068295R1
ABB
XT4S160 PART OF 4P F F INTERRUPTION
XT4S 160 BREAKING PART 4p F F
Low-voltage industrial components > Power circuit-breaker for trafo/generator/installation protection
Molded Case Circuit Breakers ≤ 250 A Xtmax
Brand new product in its original packaging covered by the warranties and certifications provided by ABB
Best sellers
▲More info
▲| ABB EcoSolutions | |
|---|---|
| ABB EcoSolutions | Yes |
| Circular Value | |
| Circular Design Principles Recyclability Rate | Design for Closing Resource Loops - Standard EN45555 - 56.30 % |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| End of Life Instructions | 9AKK108468A2351 |
| Group Waste to Landfill Target | UL 2799 Zero Waste To Landfill Validation available |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| Eco Transparency | |
| Environmental Product Declaration - EPD | 9AKK108469A1857 |
| 9AKK108468A1892 | |
| Environmental | |
| Environmental Information | 9AKK108467A6707 |
| REACH Declaration | 9AKK108466A1425 |
| RoHS Information | 9AKK108466A1424 |
| RoHS Status | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| SCIP | ff8f6b2e-2cf2-4ef3-bc09-d8807c6d04ea Italy (IT) |
| Simplified SCIP | 9f9e86e9-c5ad-4b07-8e1c-f6cc254c9bd6 Hungary (HU) |
| 08de2cee-3226-4e30-b6dc-a0fc5a8dc371 France (FR) | |
| 64e86673-90e4-4e9e-b09e-803f3f7891c7 Spain (ES) | |
| 434f92c0-229b-4f37-aded-b6214f71bf3d Belgium (BE) | |
| f0f87fd8-8c67-47b8-bbf0-587134dbcc3e Germany (DE) | |
| 99478079-21f7-460d-a8fd-3643c2a03a03 Czech Republic (CZ) | |
| 30f01bbb-3752-42da-837f-3389998ddc0a Germany (DE) | |
| c91e8fb5-c9cb-49fe-a538-bffb95b18922 Sweden (SE) | |
| 7a1a3749-2a66-4f18-8979-e591cce0f730 Denmark (DK) | |
| 3e7af871-f903-4db5-8c72-bc4ea8374396 Germany (DE) | |
| 9e82698c-7c8a-4893-8438-a6a813a9f8d4 Croatia (HR) | |
| c6db457a-16ba-4e59-9e83-fac9daa25fde Germany (DE) | |
| 94d2d19f-4be4-4c48-aa94-bb0605b36de8 Poland (PL) | |
| 68614f4a-af89-42ae-9ecd-03d00eab6508 Poland (PL) | |
| 8bbbf0b6-f128-4945-932c-771692424cfc Bulgaria (BG) | |
| c411ee69-9a36-4446-b010-90f87755c1ca Sweden (SE) | |
| f6f1b87d-27bd-4f2c-b9c2-1129274d11cb Netherlands (NL) | |
| fb38565e-71eb-4d26-b47c-2d949fb7fdb0 Norway (NO) | |
| 777f1d13-21b3-4a78-a3bc-ef8b0dbc686f France (FR) | |
| d7e5f17f-8221-4ded-977c-407ab56d71e5 Greece (GR) | |
| ff126bdc-7cac-4af9-9b2c-a70998cb9eaf Germany (DE) | |
| b8fb8899-2763-4dad-a83a-cd009acba78d Portugal (PT) | |
| ff6e3995-96fe-4d7f-adbf-91cb89d51682 Estonia (EE) | |
| 2f98ecba-7ebe-4ab5-8296-1242eb022f4f Finland (FI) | |
| 9d09a8c8-ecd3-4f59-84b4-de7f3abf292a Poland (PL) | |
| 5e4d6c85-1a8b-406d-b193-802f3aaa618f Hungary (HU) | |
| 8715d2ae-2a16-4fd5-8af2-21b964bae037 Belgium (BE) | |
| Ordering | |
| E-Number (Finland) | 3641072 |
| EAN | 8015644022068 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85362090 |
| Dimensions | |
| Product Net Width | 140 mm |
| Product Net Height | 160 mm |
| Product Net Depth / Length | 82.5 mm |
| Product Net Weight | 2.65 kg |
| Container Information | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 171 mm |
| Package Level 1 Height | 215 mm |
| Package Level 1 Depth / Length | 151 mm |
| Package Level 1 Gross Weight | 3.1 kg |
| Package Level 1 EAN | 8015644022068 |
| Additional Information | |
| Electrical Durability | 120 cycles per hour |
| 8000 cycle | |
| Mechanical Durability | 240 cycles per hour |
| 25000 cycle | |
| Number of Poles | 4 |
| Opening Time | CB with SOR 15 ms |
| CB with UVR 15 ms | |
| Order Multiple | 1 piece |
| Product Main Type | SACE Tmax XT |
| Product Name | Moulded Case Circuit Breaker |
| Product Type | Breaking Part |
| Rated Frequency (f) | 50 / 60 Hz |
| Rated Voltage (Ur) | 690 V |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Operational Voltage | 690 V AC |
| 500 V DC | |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (220 V AC) 85 kA |
| (230 V AC) 85 kA | |
| (240 V AC) 85 kA | |
| (380 V AC) 50 kA | |
| (415 V AC) 50 kA | |
| (440 V AC) 50 kA | |
| (500 V AC) 36 kA | |
| (525 V AC) 25 kA | |
| (690 V AC) 12 kA | |
| (250 V DC) 2 Poles in Series 50 kA | |
| (500 V DC) 2 Poles in Series 50 kA | |
| (500 V DC) 3 Poles in Series 50 kA | |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (220 V AC) 85 kA |
| (230 V AC) 85 kA | |
| (240 V AC) 85 kA | |
| (380 V AC) 50 kA | |
| (415 V AC) 50 kA | |
| (440 V AC) 50 kA | |
| (500 V AC) 36 kA | |
| (525 V AC) 25 kA | |
| (690 V AC) 12 kA | |
| (250 V DC) 2 Poles in Series 50 kA | |
| (500 V DC) 2 Poles in Series 50 kA | |
| (500 V DC) 3 Poles in Series 50 kA | |
| Rated Uninterrupted Current (Iu) | 160 A |
| Short-Circuit Performance Level | S |
| Standards | IEC60947-2 |
| Sub-type | XT4 |
| Terminal Connection Type | Front |
| Version | F |
| Certificates and Declarations | |
| Data Sheet, Technical Information | 1SDC210100D0206 |
| 1SDC210099D0206 | |
| Declaration of Conformity - CE | 9AKK106713A5529 |
| GL Certificate | 1SDL000163R0095 |
| LR Certificate | 1SDL000163R0100 |
| Instructions and Manuals | 1SDH000722R0001 |
| Classifications | |
| ETIM 7 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| ETIM 8 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| ETIM 9 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| Object Classification Code | Q |
| UNSPSC | 39120000 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370409 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG MOLDED CASE ISOMAX-TMAX 2024 EN.pdf | 71 Mbytes |
|
