2054450 OBO BETTERMANN TERMINAL S/SCREWS 61 225 FL
Reference: 61 225 FL
Code: 2054450
Manufacturer: OBO BETTERMANN
Description:
TERMINAL S/SCREWS 61 225 FL
Universal plug-in terminal, 2-pole. Tested according to EN 60998.Screwless terminal to connect electrical conductors. The type of conductor can either be flexible, multi-wire or rigid.If rigid conductors are used, an opening of the release lever is not necessary. The conductor can be plugged into the terminal directly.To extract the conductors, simply open the release lever. The strand can then be easily pulled-out.Nominal cross-section: 2 x 0.2 - 2.5 mm² multi-wire cables / single-wire conductorsRated voltage 450 V.Rated current 24 A.Stripping length: 9 mm (+1 mm).Inspection opening: Phase tester and testing pin (max. Ø 2 mm), very easily accessible on the top side of the terminalMax. approved ambient temperature according to EN 60998: -5 to +85 °C.
Categories:
- Installation, isolation and connection material > Push in terminal
- OBO BETTERMANN > VBS Connection and fastening systems - OBO BETTERMANN
Brand new product in its original packaging covered by the warranties and certifications provided by OBO BETTERMANN
- More Info
- Reviews
LAST VIEWED
MORE INFO
| Colour | Transparent |
|---|---|
| Connectable conductor cross-section, multi-wire, max. | 2,5 mm² |
| Connectable conductor cross-section, multi-wire, min. | 0,2 mm² |
| Connectable conductor cross-section, single-wire, max. | 2,5 mm² |
| Connectable conductor cross-section, single-wire, min. | 0,2 mm² |
| Cross-section | 2 x 0.2 - 2.5 mm² multi-wire cables / single-wire conductors mm² |
| Dimension | 0,2-2,5mm² |
| Flame-resistant | Acc. to VDE 0471/DIN 695 Part 2-1, test temperature 850°C |
| Height | 11,7 mm |
| Insulation material | Thermoplast |
| Length | 11,9 mm |
| Material | Polycarbonate |
| No. of terminals | 2 |
| Nominal cross-section, max. | 2,5 mm² |
|---|---|
| Nominal cross-section, min. | 0,2 mm² |
| Nominal current | 24 A |
| Nominal voltage | 450 V |
| Permitted temperature range, max. | 85 °C |
| Permitted temperature range, min. | -5 °C |
| Pole number | 1 |
| Suitable for flexible conductors | yes |
| Suitable for multi-wire conductors | yes |
| Suitable for solid conductors | yes |
| Width | 21 mm |
| With actuating levers | yes |
