PLD-60-2000B
MEANWELL
1
Available Ship on today
AC-DC Single output LED driver Constant Current (CC), Input 230VAC, Output 2.0A / 18-30VDC
LED DRIVERS > PLD
* Brand new product in its original packaging covered by the warranties and certifications provided by MEANWELL
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Name | PLD-60-2000B |
---|---|
Long Description | LED driver. Specially designed for powering LEDs directly in a steady stream. Format in plastic boxIP42. Input range180-295Vca47-63Hz. Output in constant current2000mA. Range of output voltage with current mode constant18 to 30vdcaccording to demand load. Power:60W. Efficiency typical:86%. Input class II without grounding. Factor corrector, power>0,9to 230vac at full load. Operating temperature range of caseTcfrom-30ºCup+45ºC. Dimensions (Length x Width x Height):128 x 60 x 31.5 mm 3 years of warranty. Manufacturer: MEAN WELL. The series PLD are LED drivers designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.With plastic housing, suitable for LED applications in interior. Protection against excess temperature and short circuit.Have a low cost and a high reliability. |
Country of Origin | China |
Manufacturer | MEAN WELL |
Product type | LED Driver |
Format | Box |
Subformato | IP42 |
Applications | Lighting |
Series | PLD-60 |
Warranty (Years) | 3,00 |
Height (mm) | 31.50 |
Width (mm) | 60.00 |
Long/Background | 128.00 |
Type of Entry CA | Single-phase |
AC input Min | 180,00 |
AC input Max | 295,00 |
Input frequency | 50 Hz, 60 Hz |
Input connector | Cable |
Intensity of Minimum Output (mA) | 2.000,00 |
Intensity of Output Maximum (mA) | 2.000,00 |
Output current mA | Two thousand |
Power (W) | 60,00 |
Peak Power (W) | Sixty |
Output connector | Cable |
Isolation (V) | 3.750,00 |
Approvals | CE, ENEC |
Title: | Size: | Type: |
---|---|---|
PDF CATALOG MEANWELL EN.pdf | 10 Mbytes |
