LOVATO ELECTRIC SM1RE3200 SM1RE3200 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

SM1RE3200 LOVATO MOTOR PROT.CIRC.BR. SM1R 24-32A Type E

Reference: SM1RE3200

Manufacturer: LOVATO ELECTRIC

Description:

MOTOR PROT.CIRC.BR. SM1R 24-32A - Type E
Motor protection circuit breaker TYPE E, IEC breaking capacity Icu 50kA at 400V, 24...32A
MOTOR PROTECTION SWITCH TYPE E, ICU INT. POWER AT 400V = 50KA, 24...32A

Categories:

  • Low-voltage industrial components > Motor protection circuit-breaker
  • LOVATO ELECTRIC > Motor protection circuit breakers - LOVATO ELECTRIC

Brand new product in its original packaging covered by the warranties and certifications provided by LOVATO ELECTRIC

  • More Info
  • ETIM
  • Reviews
Guarantee, repair and return.

* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

LAST VIEWED

MORE INFO

SM1RE3200

Motor protection circuit breaker TYPE E, IEC breaking capacity Icu 50kA at 400V, 24...32A

Technical specifications

Type of product:
Motor protection circuit breaker
Thermal trip adjustment range [A]:
24…32
Rated current In [A]:
32
Short-circuit current breaking capacity (Icu) at AC 400V [kA]:
50
Type of protection:
Magnetic and thermal
Type of control:
Rotary knob
Certified UL Type E:
Yes
Order codeSM1RE3200
Weight [g]340
Qty. per package1
Multiple qty. of packs per order1
Package dimensions [mm]090X047X086
Volume [cm³]363.78
Bar code [EAN13]8013975239766
HS Code85362010

166.8 £

ETIM for SM1RE3200 Low-voltage industrial controls and switchgear (EC000074)

Feature nameDevice construction (EF008240)
Feature valueComplete device in housing
Feature nameSwitch off technique (EF007007)
Feature valueThermomagnetic
Feature nameType of control element (EF006976)
Feature valueRocker lever
Feature nameType of electrical connection of main circuit (EF006819)
Feature valueScrew connection
Feature nameDegree of protection (IP) (EF005474)
Feature valueIP20
Feature nameAdjustment range undelayed short-circuit release (EF007131)
Feature value416 A
Feature nameOverload release current setting (EF002336)
Feature value24 A
Feature nameRated operating voltage (EF001435)
Feature value0 V
Feature namePhase failure sensitive (EF007400)
Feature valueYes
Feature nameWith thermal overload protection (EF006233)
Feature valueYes
Feature nameWith integrated under voltage release (EF001390)
Feature valueNo
Feature nameWith integrated auxiliary switch (EF001387)
Feature valueNo
Feature nameRated short-circuit breaking capacity Icu at 400 V, AC (EF007049)
Feature value50 kA
Feature nameNumber of poles (EF001391)
Feature value3
Feature nameRated permanent current Iu (EF001389)
Feature value32 A
Feature nameDepth (EF000049)
Feature value91 mm
Feature nameHeight (EF000040)
Feature value97 mm
Feature nameWidth (EF000008)
Feature value45 mm
