LOVATO ELECTRICMiniature and residual circuit breakersP1MS1P100 LOVATO MODULAR SWITCH DISCONNECTOR 1P 100A
LOVATO ELECTRIC P1MS1P100 P1MS1P100 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

P1MS1P100 LOVATO MODULAR SWITCH DISCONNECTOR 1P 100A

Reference: P1MS1P100

Manufacturer: LOVATO ELECTRIC

Description:

MODULAR SWITCH DISCONNECTOR - 1P 100A
Modular switch disconnector - 1P 100A
MODULAR DISCONNECTOR - 1P 100A

Categories:

  • Circuit breakers and fuses > Miniature circuit breaker (MCB)
  • LOVATO ELECTRIC > Miniature and residual circuit breakers

Brand new product in its original packaging covered by the warranties and certifications provided by LOVATO ELECTRIC

  • More Info
  • ETIM
  • Reviews
Guarantee, repair and return.

Unit Price: 37,99 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 2 weeks.

  • These delivery times are an estimate any may vary when the item order has been processed.

MORE INFO

P1MS1P100

Modular switch disconnector - 1P 100A

Technical specifications

Type of product:
Modular switch disconnectors
Number of DIN modules:
1
Number of poles:
1P
Rated current In [A]:
100
Compliance:
IEC
Order codeP1MS1P100
Weight [g]80
Qty. per package12
Multiple qty. of packs per order12
Package dimensions [mm]080X080X020
Volume [cm³]128
Bar code [EAN13]8013975267264
HS Code85369095

38.25 £

ETIM for P1MS1P100 Circuit breakers and fuses (EC000042)

Feature nameDegree of protection (IP) (EF005474)
Feature valueIP20
Feature nameVoltage type (EF000187)
Feature valueAC
Feature nameAmbient temperature during operating (EF007515)
Feature value-25 °C
Feature nameConnectable conductor cross section solid-core (EF007337)
Feature value1 mm²
Feature nameFrequency (EF000416)
Feature value50 Hz
Feature nameAdditional equipment possible (EF008148)
Feature valueYes
Feature nameFlush-mounted installation (EF007517)
Feature valueNo
Feature nameConcurrently switching neutral conductor (EF005997)
Feature valueYes
Feature nameExplosion-proof (EF004663)
Feature valueNo
Feature nameRated impulse withstand voltage Uimp (EF011980)
Feature value4 kV
Feature nameNumber of poles (total) (EF008618)
Feature value1
Feature nameNumber of protected poles (EF005548)
Feature value1
Feature nameWidth in number of modular spacings (EF002950)
Feature value1
Feature namePollution degree (EF002570)
Feature value3
Feature nameOver voltage category (EF002569)
Feature value3
Feature nameRated insulation voltage Ui (EF001366)
Feature value1000 V
Feature nameRated voltage (EF000228)
Feature value240 V
Feature nameRated current (EF000227)
Feature value100 A
Feature nameBuilt-in depth (EF000218)
Feature value66 mm

DATASHEET - PDF

Title
Size
Type
PDF CATALOGUE LOVATO EN
99 Mbytes
