HS1B5NV130D024 LOVATO SOLID STATE RELAY 1P 130A
HS1B5NV130D024
LOVATO ELECTRIC
SOLID STATE RELAY 1P 130A
Hockey puck, single-phase, 130A, 3,5...32VDC, screw terminals
RELE' STATO SOLIDO 1P 130A
Relays > Solid state relay
Home > LOVATO ELECTRIC
Brand new product in its original packaging covered by the warranties and certifications provided by LOVATO ELECTRIC
Best sellers
▲More info
▲HS1B5NV130D024
Hockey puck, single-phase, 130A, 3,5...32VDC, screw terminals
Technical specifications
- Type of product:
- Hockey puck, single-phase
- Control voltage [V]:
- 3.5...32VDC
- Rated operational voltage:
- 24…510
- Rated operating current AC-51 (resistive load) at 40°C:
- 130
- Rated operating current AC-53 (motor load) at 40°C:
- 32
- Heatsink for use at 40°C and 55°C at rated current AC-51:
- ≤0.3
- Number of poles:
- 1
- Operating temperature max:
- +90
- Specific let through energy I2t:
- 22
- Type of terminals:
- Screw
| Order code | HS1B5NV130D024 |
|---|---|
| Weight [g] | 100 |
| Qty. per package | 1 |
| Multiple qty. of packs per order | 1 |
| Package dimensions [mm] | 075X049X038 |
| Volume [cm³] | 139.65 |
| Bar code [EAN13] | 8013975321676 |
| HS Code | 85365003 |
113.14 £
| Feature Name | Feature Value |
|---|---|
| Voltage type for actuating (EF008242) | DC |
| Rated control supply voltage DC (EF003980) | 3.5 V |
| Rated operation current Ie at AC-53a (EF009489) | 32 A |
| Rated operation current Ie at AC-51 (EF009488) | 130 A |
| Number of phases (EF000351) | 1 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE LOVATO EN.pdf | 99 Mbytes |
|
