7GN6355O GN6355O LOVATO Selector switch "1-2" 2-pole GN55 63 TO Model Or 65x65
7GN6355O
GN6355O
LOVATO ELECTRIC
Selector switch "1-2" 2-pole GN55 63 TO Model Or 65x65
Switch "1-2" 2 poles GN55 63 A Model O 65x65
Rotary cam switch 7GN series, changeover switch without 0, 2 poles 63A, for rear mounting with black handle, front plate 65X65mm
ROTARY CAM SWITCH 7GN SERIES, CHANGEOVER SWITCH WITHOUT 0 2 POLES 63A, FOR REAR MOUNTING WITH BLACK HANDLE, FRONT PLATE 65X65MM
Low-voltage industrial components > Off-load switch
Rotary cam switches - LOVATO ELECTRIC
Brand new product in its original packaging covered by the warranties and certifications provided by LOVATO ELECTRIC
Best sellers
▲More info
▲7GN6355O
Rotary cam switch 7GN series, changeover switch without 0, 2 poles 63A, for rear mounting with black handle, front plate 65X65mm
Technical specifications
- Type of product:
- Changeover switches
- Switching diagram:
- 55 - Changeover switch without 0 2 poles
- IEC Conventional free air thermal current Ith [A]:
- 63
- Mounting form:
- O - Rear mounting with black handle
- Series:
- 7GN - round-shaped contact block
| Order code | 7GN6355O |
|---|---|
| Weight [g] | 300 |
| Qty. per package | 1 |
| Multiple qty. of packs per order | 1 |
| Package dimensions [mm] | 067X067X130 |
| Volume [cm³] | 583.57 |
| Bar code [EAN13] | 3850144161863 |
| HS Code | 85365080 |
| Feature Name | Feature Value |
|---|---|
| Type of control element (EF006976) | Short thumb-grip |
| Type of electrical connection of main circuit (EF006819) | Screw connection |
| Degree of protection (IP), front side (EF003118) | IP40 |
| Housing material (EF001596) | Plastic |
| Model (EF000010) | On/Off switch |
| Complete device in housing (EF007317) | Yes |
| Suitable for intermediate mounting (EF007264) | No |
| Suitable for distribution board installation (EF007262) | Yes |
| Suitable for front mounting (EF007246) | No |
| Suitable for floor mounting (EF007243) | No |
| With retraction in 0-position (EF002428) | No |
| With zero (off) position (EF001416) | No |
| Number of poles (EF001391) | 4 |
| Rated permanent current Iu (EF001389) | 63 A |
| Rated operation power at AC-3, 400 V (EF001364) | 18.5 kW |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE LOVATO EN.pdf | 99 Mbytes |
|
