GF2011U LOVATO 3PH REVERSING SW. 20A FRONT MOUNT 48X48

Reference: GF2011U

Manufacturer: LOVATO ELECTRIC

Description:

3PH REVERSING SW. 20A FRONT MOUNT 48X48
Rotary cam switch GF series, 3-phase motor reversing switch 20A, for front mounting with black handle, front plate 48X48mm

Categories:

  • Low-voltage industrial components > Selector switch, complete
  • LOVATO ELECTRIC > Rotary cam switches - LOVATO ELECTRIC

Brand new product in its original packaging covered by the warranties and certifications provided by LOVATO ELECTRIC

  • More Info
  • ETIM
  • Reviews
Guarantee, repair and return.

* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

LAST VIEWED

MORE INFO

GF2011U

Rotary cam switch GF series, 3-phase motor reversing switch 20A, for front mounting with black handle, front plate 48X48mm

Technical specifications

Type of product:
Motor starting switches
Switching diagram:
11 - 3-phase motor reversing switch
IEC Conventional free air thermal current Ith [A]:
20
Mounting form:
U - Front mounting with black handle
Series:
GF - compact series
Order codeGF2011U
Weight [g]120
Qty. per package1
Multiple qty. of packs per order1
Package dimensions [mm]050X050X103
Volume [cm³]258
Bar code [EAN13]3850144002760
HS Code85365080

58.08 £

ETIM for GF2011U Low-voltage industrial controls and switchgear (EC001029)

Feature nameType of control element (EF006976)
Feature valueShort thumb-grip
Feature nameMaterial front ring (EF005972)
Feature valuePlastic
Feature nameDegree of protection (IP) (EF005474)
Feature valueIP40
Feature nameType of electric connection (EF003961)
Feature valueScrew connection
Feature nameWith front ring (EF006014)
Feature valueNo
Feature nameWith light source (EF005905)
Feature valueNo
Feature nameSpring-return (EF001407)
Feature valueNo
Feature nameSuitable for lighting (EF001142)
Feature valueNo
Feature nameNumber of contacts as change-over contact (EF008257)
Feature value0
Feature nameNumber of contacts as normally open contact (EF008256)
Feature value3
Feature nameNumber of contacts as normally closed contact (EF008255)
Feature value0
Feature nameNumber of switch positions (EF000231)
Feature value3
