FE05D032 LOVATO FUSE 14X85 GPV 32A
FE05D032
LOVATO ELECTRIC
FUSE 14X85 GPV 32A
Fuse for photovoltaic applications, for 14X85mm fuses. 10kA breaking capacity at 1500VDC, 32A
Circuit breakers and fuses > Cylindrical fuse
Fuse holders and fuses - LOVATO ELECTRIC
Brand new product in its original packaging covered by the warranties and certifications provided by LOVATO ELECTRIC
Best sellers
▲More info
▲FE05D032
Fuse for photovoltaic applications, for 14X85mm fuses. 10kA breaking capacity at 1500VDC, 32A
Technical specifications
- Type of product:
- Fuses for PV applications - 14x85mm
- Type of operating voltage:
- DC
- IEC maximum rated voltage Un [V]:
- 1500
- IEC maximum rated current In [A]:
- 32
- Compliance:
- IEC
- For photovoltaic application:
- Yes
| Order code | FE05D032 |
|---|---|
| Weight [g] | 31 |
| Qty. per package | 5 |
| Multiple qty. of packs per order | 5 |
| Package dimensions [mm] | 145X085X015 |
| Volume [cm³] | 36.975 |
| Bar code [EAN13] | 8013975299814 |
| HS Code | 85389099 |
| Feature Name | Feature Value |
|---|---|
| Utilization category according to IEC 60269 (EF002572) | gPV (photovoltaic protection) |
| Release characteristic (EF000889) | Other |
| Voltage type (EF000187) | DC |
| Size (EF000088) | Other |
| Model (EF000010) | Ceramic fuse |
| Power loss at rated current (EF012389) | 8 W |
| Rated current (EF000227) | 32 A |
Datasheet - PDF
