BFS3222D024 LOVATO 3P 32A AC3 24V DC safety contactor
BFS3222D024
LOVATO ELECTRIC
3P 32A AC3 24V DC safety contactor
SAFETY CONTACTOR 3P 32A AC3 24V DC
Three-pole safety contactor, IEC operating current Ie (AC3) = 32A, DC coil, 24VDC, 2NO+2NC auxiliary contact
Industrial Contactors and Accessories - LOVATO ELECTRIC
Brand new product in its original packaging covered by the warranties and certifications provided by LOVATO ELECTRIC
Best sellers
▲More info
▲BFS3222D024
Three-pole safety contactor, IEC operating current Ie (AC3) = 32A, DC coil, 24VDC, 2NO+2NC auxiliary contact
Technical specifications
- Type of product:
- Contactors
- Number of poles:
- 3
- Type of coil:
- DC coil
- Rated coil voltage [V]:
- 24
- IEC operating current Ith (AC1) [A]:
- 56
- IEC operating current and power Ie (AC3) 400V [A/Kw]:
- 32A / 16Kw
- UL/CSA horsepower ratings 480V [HP]:
- 20
- Type of built-in auxiliary contacts:
- 0
- Type of mounting:
- Screw / DIN rail 35mm
| Order code | BFS3222D024 |
|---|---|
| Weight [g] | 650 |
| Qty. per package | 1 |
| Multiple qty. of packs per order | 1000 |
| Package dimensions [mm] | 150X050X100 |
| Volume [cm³] | 750 |
| Bar code [EAN13] | 8013975325940 |
| HS Code | 85365080 |
154.85 £
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE LOVATO EN.pdf | 99 Mbytes |
|
