7GN2097O48 GN2097O48 LOVATO AMMETER SWITCH 20A MODULAR 35MM DIN RAIL
7GN2097O48
GN2097O48
LOVATO ELECTRIC
AMMETER SWITCH 20A MODULAR 35MM DIN RAIL
Rotary cam switch 7GN series, ammeter switch 20A, modular service cover for 35mm DIN reail mounting with black handle, front plate 45X54mm
ROTARY CAM SWITCH 7GN SERIES, AMMETER SWITCH 20A, MODULAR SERVICE COVER FOR 35MM DIN RAIL MOUNTING WITH BLACK HANDLE, FRONT PLATE 45X54MM
Low-voltage industrial components > Selector switch, complete
Rotary cam switches - LOVATO ELECTRIC
Brand new product in its original packaging covered by the warranties and certifications provided by LOVATO ELECTRIC
Best sellers
▲More info
▲7GN2097O48
Rotary cam switch 7GN series, ammeter switch 20A, modular service cover for 35mm DIN reail mounting with black handle, front plate 45X54mm
Technical specifications
- Type of product:
- Voltmeters and ammeters
- Switching diagram:
- 97 - Ammeter switch
- IEC Conventional free air thermal current Ith [A]:
- 20
- Mounting form:
- O48 - Modular service cover for 35mm din rail mounting with black handle
- Series:
- 7GN - round-shaped contact block
| Order code | 7GN2097O48 |
|---|---|
| Weight [g] | 140 |
| Qty. per package | 1 |
| Multiple qty. of packs per order | 1 |
| Package dimensions [mm] | 050X050X144 |
| Volume [cm³] | 360 |
| Bar code [EAN13] | 3850144038776 |
| HS Code | 85365080 |
| Feature Name | Feature Value |
|---|---|
| Type of control element (EF006976) | Short thumb-grip |
| Material front ring (EF005972) | Plastic |
| Degree of protection (IP) (EF005474) | IP40 |
| Type of electric connection (EF003961) | Screw connection |
| With front ring (EF006014) | No |
| With light source (EF005905) | No |
| Spring-return (EF001407) | No |
| Suitable for lighting (EF001142) | No |
| Number of contacts as change-over contact (EF008257) | 0 |
| Number of contacts as normally open contact (EF008256) | 5 |
| Number of contacts as normally closed contact (EF008255) | 0 |
| Height opening (EF004778) | 45 mm |
| Width opening (EF004565) | 54 mm |
| Number of switch positions (EF000231) | 4 |
| Hole diameter (EF000079) | 45 mm |
