SK825400-AM ABB KH210 230-240V 50Hz Operating Coil
SK825400-AM
ABB
KH210 230-240V 50Hz Operating Coil
Spare parts Power Switches ABB
Brand new product in its original packaging covered by the warranties and certifications provided by ABB
Best sellers
▲More info
▲| Ordering | |
|---|---|
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85369001 |
| Popular Downloads | |
| Data Sheet, Technical Information | 1SDC001007D0205 |
| Instructions and Manuals | 5309660-57 |
| Dimensions | |
| Product Net Width | 200 mm |
| Product Net Depth / Length | 200 mm |
| Product Net Height | 175 mm |
| Product Net Weight | 0.36 kg |
| Technical | |
| Rated Control Circuit Voltage (Uc) | 50 Hz 230 ... 240 V |
| Suitable For | EH175 |
| EH210 | |
| EK110 | |
| EK150 | |
| EHDB220 | |
| EHDB280 | |
| Suitable for Product Class | Block Contactors |
| Product Name | Operating Coil |
| Material Compliance | |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| REACH Declaration | 2CMT2021-006202 |
| RoHS Declaration | 2CMT2021-006277 |
| Toxic Substances Control Act - TSCA | 2CMT2023-006525 |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| ABB EcoSolutions | |
| Certificates and Declarations | |
| Declaration of Conformity - CE | N/A |
| Container Information | |
| Package Level 1 Units | bag 1 piece |
| Package Level 1 Width | 240 mm |
| Package Level 1 Depth / Length | 240 mm |
| Package Level 1 Height | 190 mm |
| Package Level 1 Gross Weight | 0.4 kg |
| Package Level 1 EAN | 7320500061855 |
| External Classifications and Standards | |
| Object Classification Code | M |
| ETIM 7 | EC002498 - Accessories for low-voltage switch technology |
| ETIM 8 | EC002498 - Accessories/spare parts for low-voltage switch technology |
| UNSPSC | 39121000 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG SPARE PARTS CIRCUIT BREAKERS EN.pdf | 26 Mbytes |
|
