SCAMESwitches - SCAME590.FEM16005 SCAME SWITCH DISCONNECTOR 160A 3P+N IP65
SCAME 590.FEM16005 590.FEM16005 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

590.FEM16005 SCAME SWITCH DISCONNECTOR 160A 3P+N IP65

Reference: 590.FEM16005

Manufacturer: SCAME

Description:

SWITCH DISCONNECTOR 160A 3P+N IP65
MANOEUVRING INT. 160A 3P+N IP65
160A 3P+N IP65 315x410x150mm FR3 IK08 EMERGENCY YELLOW/RED FIRE RATED

Categories:

  • Low-voltage industrial components > Switch disconnector
  • SCAME > Switches - SCAME

Brand new product in its original packaging covered by the warranties and certifications provided by SCAME

  • More Info
  • PDF
  • Reviews
Guarantee, repair and return.

Unit Price: 762,82 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 20 days.

  • These delivery times are an estimate any may vary when the item order has been processed.

MORE INFO

Commercial Series
ISOLATORS-FR Series
Synthetical description
SWITCH DISCONNECTOR
Construction type
Enclosed
Mounting version
SURFACE MOUNTING
Material
DIE-CAST ALUMINIUM
Protection degree IP
IP65
Installation temperature
-25°C/+60°C
Type
EMERGENCY
Colour
YELLOW/RED
Rated current
160A
Poles
3P+N
Switch size
FR3
Rated voltage
690V
Dimensions
315x410x150mm
Notes
FIRE RATED
Fire rated class
F400 (120min)
Protection degree IK
IK08
Rated insulation voltage (Ui)
800VAC
Rated impulse voltage (Uimp)
8kV
Thermal current (Ithe)
160A
Current (Ie) in AC21A (415V)
160A
Current (Ie) in AC22A (415V)
160A
Current (Ie) in AC23A (415V)
160A
Power AC23A (415V)
69kW
Short-time current
3kA Icw(1s)
Conditional short circuit cur.
69kAeff
Associate fuse - type gG
125A
Terminals - Flexible wires
10-70mm²
Terminals - Rigid wires
10-70mm²
Catalogue notes
Handle padlockable in OFF (3 padlocks) and ON (1 padlock) position
Equipped with door interlock
Blank sides
With late break and early make neutral pole

DATASHEET - PDF

Title
Size
Type
590.FEM16005 590.FEM16005 EN_590.FEM16005.pdf
69 Kbytes
PDF CATALOGUE SCAME EN
20 Mbytes
