OMRONSafetyD4ND4N-4C22 D4N 0281M D4N4C22 OMRON Plastic 2NC/1NO Slow Roller plunger Metal, M20
OMRON D4N-4C22 D4N 0281M D4N4C22 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

D4N-4C22 D4N 0281M D4N4C22 OMRON Plastic 2NC/1NO Slow Roller plunger Metal, M20

Reference: D4N-4C22

Code: D4N 0281M

Catalog Number: D4N4C22

Manufacturer: OMRON

Description:

Plastic 2NC/1NO Slow Roller plunger Metal, M20
Plastic 2NC/1NA Slow Roller Metal M20
Limit switch, Roller lever (metal lever, resin roller), 2NC/1NO (slow-action), 2NC/1NO (slow-action), M20 (1-conduit)

Categories:

  • Sensors > End switch
  • OMRON > Safety > D4N

Brand new product in its original packaging covered by the warranties and certifications provided by OMRON

  • More Info
  • ETIM
  • PDF
  • Reviews
Guarantee, repair and return.

Unit Price: 41,85 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 4-5 weeks.

  • These delivery times are an estimate any may vary when the item order has been processed.

MORE INFO

  • Direct opening mechanism and approval by notified body
  • Rugged plastic housing with double insulation
  • Wide range of actuators
  • M12 connectors or terminal block with M20 conduit

ETIM for 170357 Sensors (EC000030)

Feature nameExplosion safety category for dust (EF003998)
Feature valueNone
Feature nameConstruction type housing (EF004008)
Feature valueCuboid
Feature nameDegree of protection (NEMA) (EF011959)
Feature valueOther
Feature nameCoating housing (EF001601)
Feature valueOther
Feature nameDegree of protection (IP) (EF005474)
Feature valueIP67
Feature nameAlignment of the control element (EF008793)
Feature valueRoller cam straight
Feature nameType of control element (EF006976)
Feature valueRoller lever
Feature nameType of interface for safety communication (EF003956)
Feature valueNone
Feature nameType of electric connection (EF003961)
Feature valueCable entry metrical
Feature nameType of interface (EF006977)
Feature valueNone
Feature nameSwitching function (EF000189)
Feature valueSlow-action switch
Feature nameHousing material (EF001596)
Feature valuePlastic
Feature nameExplosion safety category for gas (EF003997)
Feature valueNone
Feature nameSwitching function latching (EF007447)
Feature valueNo
Feature nameWith status indication (EF001602)
Feature valueNo
Feature nameSuitable for safety functions (EF001597)
Feature valueYes
Feature nameForced opening (EF006694)
Feature valueYes
Feature nameOutput electronic (EF006987)
Feature valueNo
Feature nameNumber of contacts as change-over contact (EF008257)
Feature value0
Feature nameNumber of contacts as normally open contact (EF008256)
Feature value1
Feature nameRated operation current Ie at AC-15, 230 V (EF001385)
Feature value3 A
Feature nameRated operation current Ie at DC-13, 125 V (EF007085)
Feature value0.55 A
Feature nameNumber of safety auxiliary contacts (EF006940)
Feature value0
Feature nameRated operation current Ie at DC-13, 230 V (EF001386)
Feature value0.27 A
Feature nameNumber of contacts as normally closed contact (EF008255)
Feature value2
Feature nameRated operation current Ie at AC-15, 125 V (EF007082)
Feature value6 A
Feature nameWidth sensor (EF007094)
Feature value31 mm
Feature nameHeight of sensor (EF007283)
Feature value107.75 mm
Feature nameLength of sensor (EF007334)
Feature value30 mm
Feature nameAmbient temperature during operating (EF007515)
Feature value-30 °C
