CP1W-CIF01 CP1W9273H CP1WCIF01,1 OMRON Интерфейс RS-232C для CP1
CP1W-CIF01
CP1W9273H
CP1WCIF01.1
OMRON
Интерфейс RS-232C для CP1
Опциональная плата последовательной связи CP1 RS-232C (макс. 15 м)
Программируемые логические контроллеры (ПЛК) > Блок передачи данных ПЛК
Системы управления > CP1
Новый продукт в оригинальной упаковке со всеми гарантиями и сертификатами OMRON
Best sellers
▲Описание
▲| Характеристика | Значение |
|---|---|
| Explosion safety category for dust (EF003998) | None |
| Performance level according to EN ISO 13849-1 (EF007399) | Level a |
| Type of data transmission (EF008225) | Serial |
| SIL according to IEC 61508 (EF009889) | None |
| Explosion safety category for gas (EF003997) | None |
| Radio standard UMTS (EF008525) | No |
| Supporting protocol for PROFIsafe (EF007526) | No |
| Certified for UL hazardous location class III (EF017627) | No |
| Supporting protocol for PROFIBUS (EF003052) | No |
| Radio standard GPRS (EF008523) | No |
| Supporting protocol for EtherCAT (EF017564) | No |
| Certified for UL hazardous location class II (EF017625) | No |
| Appendant operation agent (Ex ib) (EF004142) | No |
| Certified for UL hazardous location class I (EF017622) | No |
| Supporting protocol for DeviceNet Safety (EF007520) | No |
| Supporting protocol for TCP/IP (EF003050) | No |
| Supporting protocol for other bus systems (EF003062) | No |
| Supporting protocol for Foundation Fieldbus (EF007522) | No |
| Supporting protocol for SafetyBUS p (EF007527) | No |
| Supporting protocol for SERCOS (EF006657) | No |
| Appendant operation agent (Ex ia) (EF004141) | No |
| IO link master (EF007298) | No |
| Supporting protocol for Modbus (EF003057) | Yes |
| Supporting protocol for KNX (EF003055) | No |
| Redundancy (EF003156) | No |
| Certified for UL hazardous location group G (non-conductive dusts) (EF017639) | No |
| Supporting protocol for PROFINET CBA (EF007524) | No |
| Certified for UL hazardous location group F (carbonaceous dusts) (EF017638) | No |
| Supporting protocol for LON (EF003017) | No |
| Supporting protocol for SUCONET (EF003060) | No |
| Radio standard Bluetooth (EF007178) | No |
| Suitable for safety functions (EF001597) | No |
| Certified for UL hazardous location group E (metal dusts) (EF017637) | No |
| With optical interface (EF003028) | No |
| Supporting protocol for EtherNet/IP (EF007521) | No |
| Supporting protocol for CAN (EF003053) | No |
| Supporting protocol for AS-Interface Safety at Work (EF007519) | No |
| Radio standard WLAN 802.11 (EF007179) | No |
| Certified for UL hazardous location group A (acetylene) (EF017632) | No |
| Radio standard GSM (EF008524) | No |
| Supporting protocol for INTERBUS (EF003054) | No |
| Certified for UL hazardous location division 2 (EF017629) | No |
| Supporting protocol for Data-Highway (EF003058) | No |
| Certified for UL hazardous location division 1 (EF017628) | No |
| Supporting protocol for PROFINET IO (EF007525) | No |
| Certified for UL hazardous location group D (propane) (EF017636) | No |
| Supporting protocol for ASI (EF003051) | No |
| Certified for UL hazardous location group C (ethylene) (EF017635) | No |
| Supporting protocol for DeviceNet (EF003059) | No |
| Supporting protocol for INTERBUS-Safety (EF006662) | No |
| Certified for UL hazardous location group B (hydrogen) (EF017633) | No |
| With potential separation (EF003272) | No |
| Number of HW-interfaces CAN (EF017563) | 0 |
| Number of HW-interfaces other (EF003027) | 0 |
| Number of HW-interfaces parallel (EF003026) | 0 |
| Number of interfaces PROFINET (EF006932) | 0 |
| Number of HW-interfaces industrial Ethernet (EF003020) | 0 |
| Number of HW-interfaces USB (EF003025) | 0 |
| Width (EF000008) | 35 mm |
| Number of HW-interfaces RS-232 (EF003021) | 1 |
| Number of HW-interfaces RS-422 (EF003022) | 0 |
| Number of HW-interfaces RS-485 (EF003023) | 0 |
| Number of HW-interfaces serial TTY (EF003024) | 0 |
| Height (EF000040) | 35 mm |
| Depth (EF000049) | 13.5 mm |
| Number of HW-interfaces wireless (EF006933) | 0 |
Datasheet - PDF
▲| Заглавие: | Размер: | Тип: |
|---|---|---|
| PDF CATALOGO OMRON AUTOMATION EN.pdf | 19 Mbytes |
|
| PDF CATALOG OMRON RU.pdf | 70 Mbytes |
|
| CP1W-CIF01 CP1WCIF01.1 CP1W9273H cj2_series_brochure_ru.pdf | 3 Mbytes |
|
| CP1W-CIF01 CP1WCIF01.1 CP1W9273H v301_cs_cj_spu_storage_and_processing_units_brochure_en.pdf | 2 Mbytes |
|
