414447 LEGRAND DISJ C CONTINUOUS 1000V 2P 13A

The circuit breaker is specifically designed for direct current applications, such as photovoltaic installations and renewable energy systems that require high levels of safety and reliability. This device guarantees the effective protection of the circuits against overloads and short circuits, ensuring the continuity of the service and the integrity of the electrical installation.

Installation Depth	44 mm
Shot curve	B
Number of poles (total)	2
Number of protected poles	2
Nominal current	13 A
Nominal voltage	1000 V
Nominal insulation voltage Ui	1000 V
Assigned Voltage Peak Resistance (Uimp)	8 kV
Type of voltage	CC
Flush mounting	Yes
Neutral Conductor Coupling	No
Degree of contamination	2
Additional equipment possible	Yes
Width in number of modular spaces	6
Protection Class (IP)	IP20
Connectable conductor section (Min-Max)	1.5-35 mm²

Solid Pluggable Conductor Section (Min-Max)	1.5-50 mm²
Explosion protection	No
Width	70.8 mm
Height	88 mm
Depth	76 mm
Impact resistance	IK02
Storage Temperature (Min-Max)	-40-70 °C
Direction of the electricity supply	From above
Display of markings on the connection terminals	Yes
Colour	Grey
RAL number	7035
Halogen-free	Yes
Connection Method	Screw-on terminal
Connection type	Cable
Label Space/Print Area	Yes
Type of mounting	DIN Lane
