IME412927 IME *RED PILOT 1MOD
IME 412927 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

412927 IME *RED PILOT 1MOD

Code: 412927

Manufacturer: IME

Description:

*RED PILOT 1MOD
Pilot light - 250V~ - red

Categories:

  • Devices for distribution board-/surface mounting > Indicator light for distribution board
  • IME

Brand new product in its original packaging covered by the warranties and certifications provided by IME

  • More Info
  • ETIM
  • PDF
  • Reviews
Guarantee, repair and return.

* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

  • These delivery times are an estimate any may vary when the item order has been processed.

MORE INFO

Pilot 1 Red module. LED indicators - Equipped with a non-interchangeable LED - LED lifespan: 100,000 h - LED consumption: - 0.17 W at 230V~/ - 0.11 W at 24V~ - Comply with IEC 60947-5-1 standard - Accept the passage of the power comb Simple - 110/400V~ - Red - Number of modules: 1. Pushbuttons - switches and pilots.
Hood colorRed
LampLED
Lamp BaseOther
Lamp power max.0.5 W
Nominal voltage400 V
Type of voltageAC
Width in number of modular spaces1
Installation Depth44 mm
Protection Class (IP)IP40
Width17.8 mm
Height93.4 mm
Depth67.3 mm
Impact resistanceIK04
Operating Temperature (Min-Max)-25-70 °C
Storage Temperature (Min-Max)-40-70 °C
Frequency (Min-Max)50-60 Hz
Estimated bulb life100000 h
Direction of the electricity supplyFrom the top or bottom
Display of markings on the connection terminalsYes
ColourGrey
RAL number7035
Halogen-freeYes
Connection MethodScrew-on terminal
Terminal Capacity (Min-Max)0.75-4 mm²
Connection typeCable
Label Space/Print AreaYes
Type of mountingDIN Lane

ETIM for 412927 Modular devices for distribution board/surface mounting (EC001657)

Feature nameMax. lamp power (EF000260)
Feature value0.5 W
Feature nameLamp socket (EF004870)
Feature valueOther
Feature nameDegree of protection (IP) (EF005474)
Feature valueIP40
Feature nameWidth in number of modular spacings (EF002950)
Feature value1
Feature nameVoltage type (EF000187)
Feature valueAC
Feature nameLamp type (EF002423)
Feature valueLED
Feature nameColour calotte (EF004668)
Feature valueRed
Feature nameBuilt-in depth (EF000218)
Feature value44 mm
Feature nameRated voltage (EF000228)
Feature value400 V

DATASHEET - PDF

Title
Size
Type
412927 EN_412926.pdf
356 Kbytes
PDF CATALOGUE IME EN
17 Mbytes
