DABP121206GE ELDON Распределительная коробка, 120x122x56
DABP121206GE
ELDON
Распределительная коробка, 120x122x56
Коробка для клемм, 120x122x56, без ПВ, АБС, класс защиты IP66
The ABS terminal box range, DABP, with a IP 66, 67 protection degree, is available off the shelf in many different sizes. The DABP range is well suited for demanding environments, since water and dust are prevented from entering the terminal box, thus eliminating the risk for component failure, and with that unnecessary downtime.
Клеммная коробка, 120x122x56, без MP, ABS, IP66
Щиты распределительные > Корпус шкафа (пустой)
Коробки выводов
Новый продукт в оригинальной упаковке со всеми гарантиями и сертификатами ELDON
Related products
▲Best sellers
▲Описание
▲Technical data
Description: | ABS box, halogen-free, suitable for indoor use. Low UV radiation resistance. |
Material: | ABS. Transparent cover: polycarbonate. |
Gasket: | Polyurethane gasket integrated in the box cover. |
Temperature resistance: | -40 °C to +60 °C. |
Flammability: | UL94 HB. |
Protection: | IP 66, 67 IK 06 (-25 °C), IK 07 (+35 °C). |
Finish: | RAL 7035. |
Delivery: | Body, cover, cover screws manufactured from stainless steel, mounting screws and cover plugs made from polyamide. |
Features
Feature: | ABS terminal box, available in a wide range of sizes, with a high IP 66, 67 protection degree. |
Advantage: | Customers can choose terminal boxes that meet their size requirements, off the shelf. The installed components inside the terminal box will be safe and secure due to the high protection degree. |
Benefit: | Customers can receive terminal boxes with a short delivery time, that match their size requirements. This will also remove any extra costs due to oversizing. Component failure and unnecessary downtime is avoided as water and dust are prevented from entering the terminal box. |
Comment: | The mounting plate, DMP, and DIN profiles, DR, have to be ordered separately, in order to complete the installation of the terminal box. |
| Характеристика | Значение |
|---|---|
| Mounting method (EF000003) | Surface mounted |
| Type of covering (EF000339) | Cover |
| Cover model (EF009212) | Closed |
| Type of door (EF004464) | None |
| Transparent cover/door (EF006244) | No |
| With lock (EF006306) | No |
| Height (EF000040) | 120.00 mm |
| Width (EF000008) | 122.00 mm |
| Depth (EF000049) | 56.00 mm |
| RAL-number (EF000116) | 7.04 |
| Number of modules (EF004427) | 0.00 |
| Number of rows (EF000266) | 0.00 |
| Number of openings for flange plates (EF009554) | 0.00 |
| Extension possible (EF001088) | No |
| Number of conduit inlets (EF000437) | 0.00 |
| Housing material (EF001596) | Plastic |
| With mounting plate (EF000118) | No |
| Suitable for outdoor use (EF003532) | Yes |
| Suitable for lightning protection (EF007800) | No |
| Degree of protection (IP) (EF005474) | IP67 |
| Protection class according to IEC 61140 (EF000004) | II |
| Impact strength (EF004293) | IK07 |
| Circuit integrity (EF001613) | None |
Datasheet - PDF
▲| Заглавие: | Размер: | Тип: |
|---|---|---|
| PDF CATALOGUE NVENT EN.pdf | 140 Mbytes |
|
| DABP121206GE DABP121206GE RU_DABP050504GE.pdf | 439 Kbytes |
|
