187F3712 DANFOSS HEATING SonoSensor 30 DN80 qp40 300fl PN25 2,5 м
187F3712
DANFOSS HEATING
SonoSensor 30 DN80 qp40 300fl PN25 2,5 м
Energy meters, SonoSensor 30, 80 mm, qp [m³/h]: 40.0, Heating, Battery 1 A-cell, 2 pulse output
Home > DANFOSS HEATING
Новый продукт в оригинальной упаковке со всеми гарантиями и сертификатами DANFOSS HEATING
Best sellers
▲Описание
▲Flow sensor for commercial and residential applications
Product details
| Gross weight | 11.866 Kg |
| Net weight | 15.5 Kg |
| Volume | 15.75 Liter |
| EAN | 5702428002509 |
| Gross weight | 11.866 Kg |
| Net weight | 15.5 Kg |
| Volume | 15.75 Liter |
| EAN | 5702428002509 |
| 1 Primary battery SUM weight Kg | 0.019 |
| 1 Primary battery weight Kg | 0.019 |
| Accuracy standard | Class 2 to EN1434 |
| Ambient class | E2/M1 |
| Ambient humidity [% RH] [Max] | 93 % |
| Ambient temperature [°C] [max] | 55 °C |
| Ambient temperature [°C] [min] | 5 °C |
| Application | Heating |
| Approval authority | MID |
| Battery lifetime [Years] | 12 yr |
| Battery qty | 1 |
| Battery type or Name | AA Lithium |
| Cable length between calculator and flow sensor [m] | 2.5 m |
| Connection size | DN 80 |
| Connection types | Flange |
| Description | Flow sensor for commercial and residential applications |
| Diameter [mm] | 80 mm |
| Dynamic range | 1:100 |
| Flow measuring principle | Ultrasonic |
| In scope of WEEE and contain batteries | Yes |
| Integrated communication | 2 pulse output |
| IP protection class | IP65 |
| Length [mm] | 350 mm |
| Media | Water quality with pH 7 to 9.5 |
| Media temperature [°C] [Max] | 130 °C |
| Media temperature [°C] [Min] | 5 °C |
| Media temporary overload temperature [°C] | 150 °C |
| Pressure nominal [bar] | 25 bar |
| Product group | Energy meters |
| Pulse value volume [l/pulse] | 10 l/pulse |
| qp [m³/h] | 40 m³/h |
| SCIP dossier no. | 45e37293-4903-4da8-85c6-f45db225394d |
| SCIP dossier product name | SonoSensor 30 1 |
| Supply voltage [V] DC | 4 V |
| Supply voltage type | Battery 1 A-cell |
| Type | SonoSensor 30 |
| Weight per battery | 19 g |
| 1 Primary battery SUM weight Kg | 0.019 |
| 1 Primary battery weight Kg | 0.019 |
| Accuracy standard | Class 2 to EN1434 |
| Ambient class | E2/M1 |
| Ambient humidity [% RH] [Max] | 93 % |
| Ambient temperature [°C] [max] | 55 °C |
| Ambient temperature [°C] [min] | 5 °C |
| Application | Heating |
| Approval authority | MID |
| Battery lifetime [Years] | 12 yr |
| Battery qty | 1 |
| Battery type or Name | AA Lithium |
| Cable length between calculator and flow sensor [m] | 2.5 m |
| Connection size | DN 80 |
| Connection types | Flange |
| Description | Flow sensor for commercial and residential applications |
| Diameter [mm] | 80 mm |
| Dynamic range | 1:100 |
| Flow measuring principle | Ultrasonic |
| In scope of WEEE and contain batteries | Yes |
| Integrated communication | 2 pulse output |
| IP protection class | IP65 |
| Length [mm] | 350 mm |
| Media | Water quality with pH 7 to 9.5 |
| Media temperature [°C] [Max] | 130 °C |
| Media temperature [°C] [Min] | 5 °C |
| Media temporary overload temperature [°C] | 150 °C |
| Pressure nominal [bar] | 25 bar |
| Product group | Energy meters |
| Pulse value volume [l/pulse] | 10 l/pulse |
| qp [m³/h] | 40 m³/h |
| SCIP dossier no. | 45e37293-4903-4da8-85c6-f45db225394d |
| SCIP dossier product name | SonoSensor 30 1 |
| Supply voltage [V] DC | 4 V |
| Supply voltage type | Battery 1 A-cell |
| Type | SonoSensor 30 |
| Weight per battery | 19 g |
Datasheet - PDF
