DANFOSS HEATING082H1116 DANFOSS HEATING AMD 520 15Nm mod 150s 24V
DANFOSS HEATING 082H1116 082H1116 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

082H1116 DANFOSS HEATING AMD 520 15Nm mod 150s 24V

Reference: 082H1116

Manufacturer: DANFOSS HEATING

Description:

AMD 520 15Nm mod 150s 24V
Electrical actuators, AMD 520, 15 N-m, Modulating, 150 ", Supply voltage [V] AC: 24, Supply voltage [V] DC: 24

Categories:

  • DANFOSS HEATING

Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS HEATING

  • More Info
  • PDF
  • Reviews
Guarantee, repair and return.

* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

LAST VIEWED

MORE INFO

AMD 520 15Nm mod 150s 24V

Product details

Gross weight0.619 Kg
Net weight0.619 Kg
Volume2.004 Liter
EAN5710104064703
Gross weight0.619 Kg
Net weight0.619 Kg
Volume2.004 Liter
EAN5710104064703

Actuator speed [s/°]150 s/°
Actuator typeElectrical
Ambient temperature [°C] [max]50 °C
Ambient temperature [°C] [min]-30 °C
ApplicationHVAC dampers
Control input signal Y [mA]0(4) - 20 mA
Control input signal Y [mA], impedance [Ohm]500
Control input signal Y [V]0(2) - 10 V
Control input signal Y [V], impedance [kOhm]100 kOhm
Control signal typeModulating
DescriptionAMD 520 15Nm mod 150s 24V
Frequency [Hz]50/60
Grade of enclosureIP54
In scope of WEEE and contain batteriesNo
Manual operationYes
Operating torque [Nm]15 N-m
Power consumption [W]2 W
Product groupElectrical actuators
Protection ClassII
REACH Candidate List substancesLead (CAS no. 7439-92-1)
Rotation angle [°]95 °
Safety functionNo
Speed typeStandard
Spring down (return)No
Spring upNo
Storage temperature [°C] [Max]80 °C
Storage temperature [°C] [Min]-30 °C
Supply voltage [V] AC24 V
Supply voltage [V] DC24 V
Turn time per 90° [s]150 "
TypeAMD 520
Actuator speed [s/°]150 s/°
Actuator typeElectrical
Ambient temperature [°C] [max]50 °C
Ambient temperature [°C] [min]-30 °C
ApplicationHVAC dampers
Control input signal Y [mA]0(4) - 20 mA
Control input signal Y [mA], impedance [Ohm]500
Control input signal Y [V]0(2) - 10 V
Control input signal Y [V], impedance [kOhm]100 kOhm
Control signal typeModulating
DescriptionAMD 520 15Nm mod 150s 24V
Frequency [Hz]50/60
Grade of enclosureIP54
In scope of WEEE and contain batteriesNo
Manual operationYes
Operating torque [Nm]15 N-m
Power consumption [W]2 W
Product groupElectrical actuators
Protection ClassII
REACH Candidate List substancesLead (CAS no. 7439-92-1)
Rotation angle [°]95 °
Safety functionNo
Speed typeStandard
Spring down (return)No
Spring upNo
Storage temperature [°C] [Max]80 °C
Storage temperature [°C] [Min]-30 °C
Supply voltage [V] AC24 V
Supply voltage [V] DC24 V
Turn time per 90° [s]150 "
TypeAMD 520

DATASHEET - PDF

Title
Size
Type
082H1116 082H1116 EN_082H1111.pdf
984 Kbytes
PDF CATALOGUE DANFOSS HEATING EN
11 Mbytes
