DANFOSS HEATING082H1110 DANFOSS HEATING AMD 420 10Nm mod 150s 24V
DANFOSS HEATING 082H1110 082H1110 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

082H1110 DANFOSS HEATING AMD 420 10Nm mod 150s 24V

Reference: 082H1110

Manufacturer: DANFOSS HEATING

Description:

AMD 420 10Nm mod 150s 24V
Electrical actuators, AMD 420, 10 N-m, Modulating, 150 ", Supply voltage [V] AC: 24, Supply voltage [V] DC: 24

Categories:

  • DANFOSS HEATING

Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS HEATING

  • More Info
  • PDF
  • Reviews
Guarantee, repair and return.

* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

LAST VIEWED

MORE INFO

AMD 420 10Nm mod 150s 24V

Product details

Gross weight0.57 Kg
Net weight0.53 Kg
Volume1.964 Liter
EAN5710104064581
Gross weight0.57 Kg
Net weight0.53 Kg
Volume1.964 Liter
EAN5710104064581

Actuator speed [s/°]150 s/°
Actuator typeElectrical
Ambient temperature [°C] [max]50 °C
Ambient temperature [°C] [min]-30 °C
ApplicationHVAC dampers
Control input signal Y [mA]0(4) - 20 mA
Control input signal Y [mA], impedance [Ohm]500
Control input signal Y [V]0(2) - 10 V
Control input signal Y [V], impedance [kOhm]100 kOhm
Control signal typeModulating
DescriptionAMD 420 10Nm mod 150s 24V
Frequency [Hz]50/60
Grade of enclosureIP54
In scope of WEEE and contain batteriesNo
Manual operationYes
Operating torque [Nm]10 N-m
Power consumption [W]2 W
Product groupElectrical actuators
Protection ClassII
REACH Candidate List substancesNo
Rotation angle [°]95 °
Safety functionNo
Speed typeStandard
Spring down (return)No
Spring upNo
Storage temperature [°C] [Max]80 °C
Storage temperature [°C] [Min]-30 °C
Supply voltage [V] AC24 V
Supply voltage [V] DC24 V
Turn time per 90° [s]150 "
TypeAMD 420
Actuator speed [s/°]150 s/°
Actuator typeElectrical
Ambient temperature [°C] [max]50 °C
Ambient temperature [°C] [min]-30 °C
ApplicationHVAC dampers
Control input signal Y [mA]0(4) - 20 mA
Control input signal Y [mA], impedance [Ohm]500
Control input signal Y [V]0(2) - 10 V
Control input signal Y [V], impedance [kOhm]100 kOhm
Control signal typeModulating
DescriptionAMD 420 10Nm mod 150s 24V
Frequency [Hz]50/60
Grade of enclosureIP54
In scope of WEEE and contain batteriesNo
Manual operationYes
Operating torque [Nm]10 N-m
Power consumption [W]2 W
Product groupElectrical actuators
Protection ClassII
REACH Candidate List substancesNo
Rotation angle [°]95 °
Safety functionNo
Speed typeStandard
Spring down (return)No
Spring upNo
Storage temperature [°C] [Max]80 °C
Storage temperature [°C] [Min]-30 °C
Supply voltage [V] AC24 V
Supply voltage [V] DC24 V
Turn time per 90° [s]150 "
TypeAMD 420

DATASHEET - PDF

Title
Size
Type
082H1110 082H1110 ES_082H1104.pdf
776 Kbytes
PDF CATALOGUE DANFOSS HEATING EN
11 Mbytes
