ABBMolded Case Circuit Breakers ≤ 250 A Xtmax1SDA100102R1 ABB Ekip Touch LSI In 100A XT2 3p
ABB 1SDA100102R1 1SDA100102R1 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

1SDA100102R1 ABB Ekip Touch LSI In 100A XT2 3p

Reference: 1SDA100102R1

Manufacturer: ABB

Description:

Ekip Touch LSI In=100A XT2 3p
SOLID-STATE RELEASE THREE-POLE IN AC EKIP TOUCH LSI R 100 XT2

Categories:

  • Low-voltage industrial components > Shunt release (for power circuit breaker)
  • ABB > Molded Case Circuit Breakers ≤ 250 A Xtmax

Brand new product in its original packaging covered by the warranties and certifications provided by ABB

  • More Info
  • PDF
  • Reviews
Guarantee, repair and return.

Unit Price: 567,49 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 25 days.

  • These delivery times are an estimate any may vary when the item order has been processed.

MORE INFO

b'

General Information

Extended Product Type:
Ekip Touch LSI In=100A XT2 3p
Product ID:
1SDA100102R1
EAN:
8056221001564
Catalog Description:
Ekip Touch LSI In=100A XT2 3p
Long Description:
SOLID-STATE RELEASE THREE-POLE IN AC EKIP TOUCH LSI R 100 XT2
\n

Ordering

EAN:
8056221001564
Minimum Order Quantity:
1 piece
Customs Tariff Number:
85389099

Dimensions

Product Net Width:
110 mm
Product Net Height:
100 mm
Product Net Depth / Length:
150 mm
Product Net Weight:
1 kg

Container Information

Package Level 1 Units:
1 piece
Package Level 1 Width:
110 mm
Package Level 1 Height:
100 mm
Package Level 1 Depth / Length:
150 mm
Package Level 1 Gross Weight:
1.1 kg
Package Level 1 EAN:
8056221001564

Additional Information

Circuit Breaker Type to be Associated:
Power Distribution
Configuration Type:
Loose or configurable
Current Type:
AC
Number of Poles:
3
Order Multiple:
1 piece
Product Main Type:
Accessories for Tmax XT
Product Name:
Accessory
Product Type:
ACC
Rated Current (In):
100 A
Release:
Ekip Touch LSI
Release Type:
EL
Standards:
IEC
Suitable For:
XT2

Certificates and Declarations (Document Number)

Data Sheet, Technical Information:\n1SDC210100D0205
1SDC210099D0205
Instructions and Manuals:\n1SDH002031A1002

Classifications

ETIM 6:
EC001023 - Shunt release (for power circuit breaker)
ETIM 7:
EC001023 - Shunt release (for power circuit breaker)
Object Classification Code:
Q
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
\n
'

DATASHEET - PDF

Title
Size
Type
1SDA100102R1 1SDA100102R1 EN_1SDA100102R1.pdf
260 Kbytes
PDF CATALOG MOLDED CASE ISOMAX-TMAX 2024 EN
71 Mbytes
